HAOAIRTECH dispensing booth with lcd touchable screen display for pharmacon
Brand:
HAOAIRTECH
Model number:
HA-DB-B Series
Material:
inside and outside is stainless steel304 (t=1.0mm)
OEM /ODM:
Yes
Certificated:
CE and Rosh
Start port:
Guangzhou
Delivery time:
8 working days after we get the deposit.
MOQ:
1sets
Country of Original:
China
Supply ability:
50 set/one month
Payment term:
T/T , L/C , Western union
Application:
Worker in Clean room
Product Comparison
HaoAir has the ability to meet different needs. pass boxes is available in multiple types and specifications. The quality is reliable and the price is reasonable.Compared with other same kind of products, pass boxes produced by HaoAir has the following advantages and features.
Application Scope
The best hepa filters produced by HaoAir is of high quality and is widely used in the Manufacturing Industrial Parts Filter Supplies industry.HaoAir has professional engineers and technicians, so we are able to provide one-stop and comprehensive solutions for customers.
1. The quality control for HAOAIRTECH dispensing booth is carried out meeting specified quality requirements. The product will be inspected in terms of sewing and stitching quality, appearance quality (pilling and fray), specification matching, etc.
2. dispensing booth offer the best performance for its price.
3. This product can bring huge benefits for business owners, such as its incredible safety. It can ensure a decrease in work accidents.
Product Features
LCD touchable screen display with air speed control
Negative Pressure Laminar Flow
GMP Modular design with minimized joints and seams.
Purification rank: Class100 /ISO5
Air speed: 0.45m/s+_20%
10% Exhaust air leaking (Adjustable)
Negative Pressure Laminar Flow
GMP Modular design with minimized joints and seams.
Energy Efficient high air volume fan to minimize operating cost,
5 different filters configuration available utilizing combination of G4,F8.H13,H14 and PLF Screens .
Gel sealant HEPA Air Filter(99.995%@0.3um) for high purification rankPurification rank: Class100 /ISO5
Air speed: 0.45m/s+_20%
10% Exhaust air leaking (Adjustable)
Introduction
Down Flow Booth provide operator, process and product protection by utilizing HEPA filtered unidirectional laminar air flow booth to maintain an ISO5 environment at rest within the work zone and capture particulates during open handling processes .
/ Products Parameter
MODEL | HA-DB1000 | HA-DB1500 | HA-DB2000 |
External size (mm) | 1200x1500x2400mm | 1500x1700x2400mm | 2000x1800x2400mm |
Work zone (mm) | 1100x1200x2000mm | 1400x1200x2000mm | 1900x1300x2000mm |
Purification rank | Class 100(ISO5) | ||
Air speed | 0.45m/s +_20% | ||
Material（Option） | 1: Entirety Stainless Steel 201/304/316.(T=1.2/1.5mm) | ||
Control system | 1: LCD touchable screen display with air speed adjustable and constant temperature and constant humidity data check. | ||
Noise level(dB) | <65dB | ||
Filter step | 3 Step | ||
HEPA filter | 99.995% @ 0.3um Gel sealant mini--pleats HEPA Air Filter | ||
Secondary filter | F8 pocket air filter | ||
Pre-filter Efficiency | G4 Z-Line panel air filter | ||
Power supply | 380V/50HZ OR 220V/50HZ | ||
Packing material | Standard Export Poly wood Packing(Fumigant free material) | ||
/ Specification
/ Product Details
part.2
Downflow booth
part.3
Air speed Test
Application
Down Flow Booth is designed such that through the different configurations it can be applied but not limited to the follow field : food ,electronic, robotic, nutraceutical, animal , cosmetic , biological , and pharmaceutical .
Per filter
/ Certificated
/ Our Service
Our Service
1：Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. always leads the peak in dispensing booth field.
2. Guangzhou HaoAir Purification Technology Co.,Ltd. is equipped with strong research strength, having an R&D team dedicated to developing all types of new weighing booth .
3. We will retain our values of quality, integrity, and respect. All is for producing world-class products aimed at improving the business of our customers. Our mission is to establish strong relationships with all our partners and to ensure client satisfaction by the highest quality products.
{{item.score}} Stars
{{item.pre}}%
{{item.nickname ? (item.nickname.slice(0, 2) + '*****') : item.source === 1 ? 'mall buyer' : '--'}}
{{item.comment_time}}
Review in the {{item.country}}
{{itemAttr.params_key}}: {{itemAttr.params_value}}
