stainless steel pass box clean room embedded lamps for hospital

Company Advantages
1. HAOAIRTECH cleanroom pass through box is precisely manufactured. During the production, it adopts various kinds of CNC machines such as cutting machine and punching machine.
2. This product is monitored constantly by our own quality team.
3. The product is safe and secure for people during operation. People can rest assured that potential safety hazards are not possible to occur.

TECHNICAL SPECIFICATIONS

• Self-supporting structure made of stainless steel AISI 304 Scotch Brite finished

•  electrically interlocked doors with proper gaskets

•  traffic light for door status

•  control panel

• differential pressure gauge

• HEPA filter grade F-14

• Motor fan

• Working area classification ISO 5

 Product Characteristic :



 Clean Room Dynamic Pass Boxes are designed in conformation to the international standards and are used for transferring

the material from and into the classified clean room without contaminating the air of clean room.

In the process, room door is not required to open. These can be easily installed on the wall between the classified room and unclassified room.

Products Parameter：

Air cleanliness :	ISO Class 5 / Class 100 / M 3.5 AREA
Air Velocities :	0.45 ± 0.05 mps (90 ± 20 FPM)
Air Flow :	Horizontal / Vertical
Noise Level :	Less than 65 dB
Vibration Level :	Minimum
POWER SUPPLY :	230V AC, 1-Ø, 50HZ
MOC :	GI Powder Coated / SS-304 / SS-316 / Combination
Door :	Swing Type Double Door (Double skinned) with View Panel with SS Hinges & ‘D’ Handle
	Internal Coving for easy cleaning
	Two Stage filtration
	EU7 - Intermediate Filter (95% down to 3 micron)
	EU14 - HEPA Filter - Supply / Exhaust (99.999% down to 0.3 micron)
	Fluorescent Lights (interlocked with Door)
	UV Light (interlocked with Door)
Differential Pressure Gauges :	01 No. (HEPA Filter)
Door Opening With Solid State Electronic Inter Locking Mechanism	When both door closed; both are elec. Magnet locked; For open press touch screen to release the door
	At A Time Only One Door Opened
	Audio / Visual Indication for material is kept inside the pass box
	In close condition of both door : UV Light will be on,
	When open any one door : UV will off and FL will on
DOP Port
DQ, IQ, OQ, PQ Documentation





Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. has laid a solid foundation in the field of pass box clean room .
2. Produced by the continuously developing innovative technologies, the quality of cleanroom pass box has become more competitive in this industry.
3. We have been long aware of the importance of harmonious development of economic benefits and environmental benefits. We will support environmental protection with science and technology. For example, we will introduce a multitude of environmental-friendly manufacturing facilities to reduce negative environmental impact. Our values are not only rules of behavior, but also guiding principles. Embedded in our DNA, they shape our ethical culture, producing a shared mindset that keeps ethics at the heart of our decisions and actions. Inquire! We are trying to seek and use clean energy resources to support our production. In the next phase, we will seek a more sustainable packaging way.
