We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

mini pleats air filter hepa with dop port for air cleaner 1

mini pleats air filter hepa with dop port for air cleaner 2

mini pleats air filter hepa with dop port for air cleaner 3

mini pleats air filter hepa with dop port for air cleaner 4

mini pleats air filter hepa with dop port for air cleaner 5

mini pleats air filter hepa with dop port for air cleaner 6

mini pleats air filter hepa with dop port for air cleaner 7

mini pleats air filter hepa with dop port for air cleaner

Brand:

HAOAIRTECH

Model number:

HA-HEPA-G Series

OEM /ODM:

Yes

Certificated:

Rosh

Start port:

Guangzhou

Delivery time:

8 working days after we get the deposit.

MOQ:

10sets

Country of Original:

China

Supply ability:

500set/one month

Payment term:

T/T , L/C , Western union

Application:

Clean room

Inquiry

Product Details

best hepa filters's outstanding quality is shown in the details.HaoAir is certified by various qualifications. We have advanced production technology and great production capability. best hepa filters has many advantages such as reasonable structure, excellent performance, good quality, and affordable price.

Enterprise Strength

HaoAir's initial intention is to provide service that can bring customers comfortable and secure experience.

Company Advantages
1. There are careful material selections in HAOAIRTECH hepa room filter manufacture. The materials are selected mainly in consideration of the force exerted on the element and the production cost.
2. This product is cost-effective and the quality is exceptional.
3. The product answers to the needs in the markets and will be more widely used in the future.
4. The product is currently widely adopted in the international market.

Characteristics

The Gel Seal HEPA filter use the super glass fibre filtration 0.3um particulate.
Patent technology to ensure the V type passage in low resistance.
Gel Seal gasket can 100% prevent the air leaking in operation.
Extrude and anodized aluminum frame in 69mm, 93mm, 96mm.104mm for choose.
While color metal screen to protect the filtration media without any damage .
Light weight and easy to install
Adopting the laser to scan the filter one by one ( MPPS).
100 % provide the test report for each mini-pleats HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um
Applied to the terminal filtration of the air-condition filtration system

mini pleats air filter hepa with dop port for air cleaner 9

/ Operating Conditions

Media	Super glass fibre
Frame	AL frame in 69/96/96/104mm
Gasket	Gel Seal
Media spacer	Hot melt
Screen	Metal screen
Efficiency	>99.999%@0.3um
Max Temperature	70℃
Max Humidity	100%

/ Products Parameter

Cabinet siz(mm) (WHD)	Rate Air Flow (m3/h)	Media Area (m2)	Dus Holding (g)	Rate primary Resistance (Pa)	Finally Resistance (Pa)	Efficiency
510X510X69	600	6.6	400	<200pa	400-600pa	H13-H14
636X636X69	1000	10.7	650
596X1196X69	1800	18.3	1100
636X1236X69	2100	21.3	1000
346X346X93	400	4.2	250
510X510X93	900	9.42	565
636X636X93	1500	14.9	900
636X941X93	2000	22.3	1200
626X1226X93	2800	29.8	1800
621X621X93	1380	14.19	851
636X1246X93	2800	29.8	1800
596X1196X93	2550	26.28	1577
656X994X93	2350	24.15	1449
350X350X96	500	4.68	300
514X514X96	1000	10.62	650
640X640X96	1500	16.8	1000

/ Product Details

part.1

Gel seal HEPA air filter

mini pleats air filter hepa with dop port for air cleaner 10

part.2

Mini-Pleats Media Compact

mini pleats air filter hepa with dop port for air cleaner 11

part.3

Air Filter Dust Detection Test

mini pleats air filter hepa with dop port for air cleaner 12

/ package

mini pleats air filter hepa with dop port for air cleaner 13

mini pleats air filter hepa with dop port for air cleaner 14

mini pleats air filter hepa with dop port for air cleaner 15

Company Features
1. As an experienced professional air filter hepa suppliers, Guangzhou HaoAir Purification Technology Co.,Ltd. has been working to promote vacuum cleaner hepa filter revolution.
2. hepa room filter are special for h12 hepa filter to be used at any situation.
3. The core values of Guangzhou HaoAir Purification Technology Co.,Ltd. lies in portable hepa filter . Inquire online! air purifiers hepa filter is HAOAIRTECH always operates. Inquire online! Guangzhou HaoAir Purification Technology Co.,Ltd. is making unremitting efforts to become a world leading company with high-efficiency. Inquire online! Guangzhou HaoAir Purification Technology Co.,Ltd. solely concentrates on exporting therefore, we offer very competitive prices. Inquire online!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
