We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.
HAOAIRTECH electronic pass box with conveyor line for hospital
1. HAOAIRTECH pass box controller is characterized by advanced technology with the great workmanship.
2. Compared with general products, pass box is featured with pass box controller , so it is more competitive in commercial market.
3. The great operation of pass box controller indicates the high performance of pass box .
4. People can be assured that the product is guaranteed with high safety and security standards. It can withstand heavy use without the worry of security problems.
5. If people want to keep their electricity bills down or otherwise go green, choosing this product with great efficiency levels will be a great choice.
TECHNICAL SPECIFICATIONS
Self-supporting structure made of stainless steel AISI 304 Scotch Brite finished
electrically interlocked doors with proper gaskets
traffic light for door status
control panel
differential pressure gauge
HEPA filter grade F-14
Motor fan
Working area classification ISO 5
Product Characteristic :
Clean Room Dynamic Pass Boxes are designed in conformation to the international standards and are used for transferring
the material from and into the classified clean room without contaminating the air of clean room.
In the process, room door is not required to open. These can be easily installed on the wall between the classified room and unclassified room.
Products Parameter：
| Air cleanliness : | ISO Class 5 / Class 100 / M 3.5 AREA |
| Air Velocities : | 0.45 ± 0.05 mps (90 ± 20 FPM) |
| Air Flow : | Horizontal / Vertical |
| Noise Level : | Less than 65 dB |
| Vibration Level : | Minimum |
| POWER SUPPLY : | 230V AC, 1-Ø, 50HZ |
| MOC : | GI Powder Coated / SS-304 / SS-316 / Combination |
| Door : | Swing Type Double Door (Double skinned) with View Panel with SS Hinges & ‘D’ Handle |
| Internal Coving for easy cleaning | |
| Two Stage filtration | |
| EU7 - Intermediate Filter (95% down to 3 micron) | |
| EU14 - HEPA Filter - Supply / Exhaust (99.999% down to 0.3 micron) | |
| Fluorescent Lights (interlocked with Door) | |
| UV Light (interlocked with Door) | |
| Differential Pressure Gauges : | 01 No. (HEPA Filter) |
| Door Opening With Solid State Electronic Inter Locking Mechanism | When both door closed; both are elec. Magnet locked; For open press touch screen to release the door |
| At A Time Only One Door Opened | |
| Audio / Visual Indication for material is kept inside the pass box | |
| In close condition of both door : UV Light will be on, | |
| When open any one door : UV will off and FL will on | |
| DOP Port | |
| DQ, IQ, OQ, PQ Documentation |
Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. has productive bases strategically located around the China.
2. It is important for HAOAIRTECH to keep innovative especially in the technology in this changing society.
3. The corporate mission of Guangzhou HaoAir Purification Technology Co.,Ltd. is to pass box controller . Inquire now! Guangzhou HaoAir Purification Technology Co.,Ltd. regards static pass box as its cardinal service tenet. Inquire now!
A wide variety of sizes are available for pass box and they make it possible for passing materials & parts in or out of a clear room without contaminating the controlled environment.
To maintain the clean room or critical area at highly cleanliness level by eliminating unnecessary personnel pass in and out.
A mechanical or electrical door interlocking system prevents cross-contamination by making it impossible to open both of front & rear doors at the same time. Or, trying to open a door as long as the opposed facing door either is open or ajar.
An optional HEPA or ULPA filter is available to meet your needs for designing either a laminar air flow type or air shower type pass box.
| Model | SZ-500 | SZ-800 | SZ-1000 |
| Internal Size | 500*500*500mm | 800*800*800mm | 1000*1000*1000mm |
| Material | SUS 304 / 316 or Paint stell | ||
| Interlock | Machinery lock / Electronical lock | ||
| Power | 220V / 380V 50 HZ 20 W | ||
