1. The product stands out for its high efficiency for purification. Being applied into different places under multiple situations is one of the characteristics of z line filter. The product stands out for its high efficiency for purification
2. It is certified by SGS corporation and reaches RoHS standard, We Can Help Clients Source All Types Of Pleated Air Filter, pleated furnace filters, merv 7 pleated air filters They Need Worldwide.
3. pleated filter is produced with the well-selected raw materials to ensure each piece in good condition. The product focuses on the good physical conditions of the workers in the workshop
Low cost
Light weight。
Good versatility。
Compact structure。
Double side with metal screen。
EVA gasket prevent air leakage
Introduce:
Pleats filter is suitable for primary filtration of air conditioning system. and Medium efficiency air filtration. It is mainly used to filter dust particles above 5 micron. Outer frame materials include cardboard frame, Aluminium frame and galvanized iron frame.
Filter materials include non-woven fabric, nylon mesh, activated carbon filter material, metal mesh, Protective mesh includes double-sided plastic-sprayed wire mesh and double-sided galvanized wire mesh.
Media | Non-Woven fabric and synthetic fiber |
Frame | AL/GL/SUS201/304 frame |
Gasket | Neoprene / EVA or PU |
Frame size | 24/48/96mm |
Screen | Metal screen in one side or both side |
Efficiency | G1-G4 ,F5-F8 |
Max Temperature | 80℃ |
Max Humidity | 100% |
Dimension | Rate air flow | Media area | Dust Holding(g) | Initial Resistance (pa) | Finally Resistance (pa) | Efficiency |
592x592x46 | 2600 | 0.97 | 110 | <25 | 100-200 | G1 |
130 | <30 | 100-200 | G2 | |||
160 | <40 | 100-200 | G3 | |||
200 | <45 | 150-200 | G4 | |||
592x490x46 | 2200 | 0.81 | 98 | <25 | 100-200 | G1 |
110 | <30 | 100-200 | G2 | |||
130 | <40 | 100-200 | G3 | |||
160 | <45 | 150-200 | G4 | |||
592x287x46 | 1300 | 0.48 | 50 | <25 | 100-200 | G1 |
60 | <30 | 100-200 | G2 | |||
80 | <40 | 100-200 | G3 | |||
100 | <45 | 150-200 | G4 |
Customer size is available
Application:
mainly used for: central air conditioning and centralized ventilation system pre-filtration, large- scale air compressor pre-filtration, clean return air system, pre-filtration of local high efficiency filter device.
