primary pleated air filters with cardboard frame for central air conditioning and centralized ventilation system

Company Advantages
1. Materials for pleated air filters will be pleated furnace filters to provide long service life.
2. It is less likely to accumulate water stains. Designed with a hydrophobic property, it can effectively drain the water away from its surface.
3. Guangzhou HaoAir Purification Technology Co.,Ltd.'s excellent sales group is full of foreign sales experience.



Introduce:

     Pleatted prefilter  is suitable for primary filtration of air conditioning system. and Medium efficiency air filtration.  It is mainly used to filter dust particles above 5  or 10 micron. Outer frame materials include cardboard frame, Aluminium frame and galvanized iron frame.

   Filter materials include non-woven fabric, nylon mesh, activated carbon filter material, metal mesh, Protective mesh includes double-sided plastic-sprayed wire mesh and double-sided galvanized wire mesh.

Media	Non-Woven fabric and synthetic fiber
Frame	Cardboard frame
Gasket	Neoprene / EVA or PU
Frame size	24/48/96mm
Screen	Metal  screen in one side or both side
Efficiency	G1-G4 ,F5-F8
Max Temperature	80℃
Max Humidity	100%

Dimension	Rate air flow	Media area	Dust Holding(g)	Initial Resistance (pa)	Finally Resistance (pa)	Efficiency
592x592x46	2600	0.97	110	<25	100-200	G1
			130	<30	100-200	G2
			160	<40	100-200	G3
			200	<45	150-200	G4
592x490x46	2200	0.81	98	<25	100-200	G1
			110	<30	100-200	G2
			130	<40	100-200	G3
			160	<45	150-200	G4
592x287x46	1300	0.48	50	<25	100-200	G1
			60	<30	100-200	G2
			80	<40	100-200	G3
			100	<45	150-200	G4

Customer size is available

mainly used for: central air conditioning and centralized ventilation system pre-filtration, large- scale air compressor pre-filtration, clean return air system, pre-filtration of local high efficiency filter device.

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is engaged in the development, manufacture, and sale of pleated furnace filters and relevant products on a global basis.
2. We have the best team! Our design and scheduling staff are highly experienced and together with the flexibility of our manufacturing team, they enable us to deliver high-quality products to our customers on time.
3. The biggest wish of HAOAIRTECH is to become the leading z line filter supplier in the future. Please contact us! Guangzhou HaoAir Purification Technology Co.,Ltd. has always been pursuing excellence and professionalism in the field of pleated air filters. Please contact us!
