Enterprise Strength
-
HaoAir runs the business in good faith and strives to provide professional services for customers.
Application Scope
With wide application, best hepa filters can be used in the following aspects.HaoAir is rich in industrial experience and is sensitive about customers' needs. We can provide comprehensive and one-stop solutions based on customers' actual situations.
Company Advantages1. The production equipment of HAOAIRTECH
air filter replacement is advanced and meets the requirements of international standards.
2. The product is quality certified for long life.
3. With the increasing popularity in the global market, the product shows a wide application.
4. The product quality of hepa air filter is ensured for a better global competitiveness.
Characteristics
The media material is super glass fibre for 0.3um particulate.
It is patent technology to ensure the V type passage in low resistance.
Neoprene /EVA or PU gasket prevent the air leaking in operation.
Extrude and anodized aluminum frame in 50mm, 69mm, 80mm, 90mm for choose.
While color metal screen to protect the filtration media without any damage.
Light weight and easy to install
Adopting the laser to scan the filter one by one ( MPPS).
100 % provide the test report for each mini-pleats HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um
Applied to the terminal filtration of the air-condition filtration system
/ Operating Conditions
Media | Super glass fibre |
Frame | AL/GL/SUS201/304 frame |
Gasket | Neoprene /EVA or PU |
Media spacer | Hot melt |
Frame thickness (mm) | 46/50/69/80/90/96/120 |
Screen | Metal screen |
Efficiency | >99.999%@0.3um |
Max Temperature | 70℃ |
Max Humidity | 100% |
/ Products Parameter
Dimension(mm)
(W*H*D) | Rate Air Flow
(m3/h) | Media Area
(m2) | Dust Holding (g) | Rate primary Resistance (Pa) | Finally Resistance
(Pa) |
320X320X50 | 200 | 1.99 | 120 | H13 :<200Pa H14 :<220pa | 400-600pa |
484X484X50 | 450 | 4.51 | 270 |
610X610X50 | 700 | 7.13 | 430 |
915X610X50 | 1000 | 10.58 | 650 |
1170X570X50 | 1200 | 12.57 | 750 |
1220X610X50 | 1350 | 14.04 | 850 |
320X320X69 | 250 | 2.89 | 180 |
484X484X69 | 600 | 6.55 | 400 |
610X610X69 | 1000 | 10.37 | 620 |
915X610X69 | 1500 | 15.39 | 920 |
1170X570X69 | 1800 | 18.28 | 1100 |
1220X610X69 | 2000 | 20.41 | 1230 |
484X484X96 | 1000 | 10.24 | 620 |
610X610X96 | 1500 | 16.2 | 980 |
915X610X96 | 2300 | 24.01 | 1450 |
1170X570X96 | 2800 | 28.56 | 1720 |
1220X610X96 | 3100 | 31.89 | 1920 |
/ Primary Resistance & Face Velocity Diagram
![mini pleats air filter replacement with one side gasket for electronic industry 13]()
/ Product Details
part.1
Hepa Air Filter With EVA Gasket and PU gasket
part.3
Mini-Pleats Media Compact
part.4
Air Filter Dust Detection Test
Application
Mini-pleats HEPA air filter suitable for hospital, electronic industry ,food,Pharmaceutical ,
bioengineering,precision instrument, electron semiconductors and dust-free room, national defense,aerospace field, fan filter unit, HEPA unit , air shower, dynamic pass box, dispensing booth ,softwall cleanroom, laminar flow booth and so on .
/ Our Service
Our Service
1: 100% scann air leaking test for each Mini-PleatsHEPA air flter, test report accompany all of
HEPA air filter.
2: 2 pcs in one carton .each air filter warp by PE Bag .
3: Small order is polywood packing so that we can send out by sea in LCL.
4: If order amount more than 20000USD, We accept the 100% LC at sight against with
document.
5: Free sample possible for you confirmation of quality .
/ package
Company Features1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a(n) air filter replacement manufacturer with years of production experience. We offer OEM service and small orders from customers.
2. HAOAIRTECH is equipped with highly advanced technology to speed up the production process.
3. HaoAir Purification always show a sincere and fair attitude towards our customers. Get price! The HAOAIRTECH plan is to become an internationally renowned HEPA & ULPA Air Filter supplier. Get price! HaoAir Purification can provide far more value for you than other brands. Get price! HAOAIRTECH has been supplying high quality support for clients. Get price!
