We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.
laminar flow clean bench flow laminar HAOAIRTECH Brand laminar flow hood
1. With our past experience and knowledge in this field, we are engaged in manufacturing a quality-assured range of laminar flow hood. The product is of high purification rank
2. All of our laminar flow cabinet can be designed and customized, including pattern, logo and so on. The product assures an extremely high-efficient manufacturing process
3. Compared to regular ones, clean bench is more of laminar flow clean bench in functions. The product creates a high cleanliness working environment
4. The product can withstand high temperature. HAOAIRTECH is committed to provide swift delivery, full quality service and tracking service for its costumers.
5. The product features an energy-saving performance. these products are manufactured with high precision to meet the set industry quality standards.
LCD control board with air speed control in three level at least
Negative Pressure Laminar Flow
GMP Modular design with minimized joints and seams.
2 different filters configuration available utilizing combination G1, H14 and PLF Screens .
Gel sealant HEPA Air Filter(99.995%@0.3um) for high purification rank
DOP/PAO Test port for your make the air filter efficiency test
Purification rank: Class100 /ISO5
Air speed: 0.45m/s+_20%10% Exhaust air leaking (Adjustable)
Introduction
Laminar air flow hood provide operator, process and product protection by utilizing HEPA filtered unidirectional laminar air flow booth to maintain an ISO5 environment at rest within the work zone and capture particulates during open handling processes .
MODEL | HA-DB1000 | HA-DB1500 | HA-DB2000 |
External size (mm) | 1200x1500x2400mm | 1500x1700x2400mm | 2000x1800x2400mm |
Work zone (mm) | 1100x1200x2000mm | 1400x1200x2000mm | 1900x1300x2000mm |
Purification rank | Class 100(ISO5) | ||
Air speed | 0.45m/s +_20% | ||
Material（Option） | 1: Entirety Stainless Steel 201/304/316.(T=1.2/1.5mm) | ||
Control system | 1: LCD touchable screen display with air speed adjustable and constant temperature and constant humidity data check. | ||
Noise level(dB) | <65dB | ||
Filter step | 3 Step | ||
HEPA filter | 99.995% @ 0.3um Gel sealant mini--pleats HEPA Air Filter | ||
Secondary filter | F8 pocket air filter | ||
Pre-filter Efficiency | G4 Z-Line panel air filter | ||
Power supply | 380V/50HZ OR 220V/50HZ | ||
Packing material | Standard Export Poly wood Packing(Fumigant free material) | ||
Application
Weighting booth is designed such that through the different configurations it can be applied but not limited to the follow field : food ,electronic, robotic, nutraceutical, animal , cosmetic , biological , and pharmaceutical .
/ Certificated
Our Service
1：Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
