Application Scope
HaoAir's air showers can be widely used in various fields.HaoAir provides comprehensive and reasonable solutions based on customer's specific situations and needs.
Product Details
HaoAir's pass boxes is of exquisite workmanship, which is reflected in the details.pass boxes, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.
Company Advantages1. Strict quality tests on HAOAIRTECH hepa room filter are required by the QC team. Its power source, electrical integrated system, electrical load, and current leakage have passed stipulated testing.
2. Its quality is guaranteed by the comprehensive quality control system.
3. To ensure its compliance with industry quality norms, this product is examined by our quality experts.
4. The product meets customer expectations and is now popular in the industry with broad market prospects.
5. The product has gained great popularity in the market and enjoys a vast market application.
Characteristics
The media material is super glass fibre for 0.3um particulate.
It is patent technology to ensure the V type passage in low resistance.
Neoprene /EVA or PU gasket prevent the air leaking in operation.
Extrude and anodized aluminum frame in 50mm, 69mm, 80mm, 90mm for choose.
While color metal screen to protect the filtration media without any damage.
Light weight and easy to install
Adopting the laser to scan the filter one by one ( MPPS).
100 % provide the test report for each mini-pleats HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um
Applied to the terminal filtration of the air-condition filtration system
/ Operating Conditions
Media | Super glass fibre |
Frame | AL/GL/SUS201/304 frame |
Gasket | Neoprene /EVA or PU |
Media spacer | Hot melt |
Frame thickness (mm) | 46/50/69/80/90/96/120 |
Screen | Metal screen |
Efficiency | >99.999%@0.3um |
Max Temperature | 70℃ |
Max Humidity | 100% |
/ Products Parameter
Dimension(mm)
(W*H*D) | Rate Air Flow
(m3/h) | Media Area
(m2) | Dust Holding (g) | Rate primary Resistance (Pa) | Finally Resistance
(Pa) |
320X320X50 | 200 | 1.99 | 120 | H13 :<200Pa H14 :<220pa | 400-600pa |
484X484X50 | 450 | 4.51 | 270 |
610X610X50 | 700 | 7.13 | 430 |
915X610X50 | 1000 | 10.58 | 650 |
1170X570X50 | 1200 | 12.57 | 750 |
1220X610X50 | 1350 | 14.04 | 850 |
320X320X69 | 250 | 2.89 | 180 |
484X484X69 | 600 | 6.55 | 400 |
610X610X69 | 1000 | 10.37 | 620 |
915X610X69 | 1500 | 15.39 | 920 |
1170X570X69 | 1800 | 18.28 | 1100 |
1220X610X69 | 2000 | 20.41 | 1230 |
484X484X96 | 1000 | 10.24 | 620 |
610X610X96 | 1500 | 16.2 | 980 |
915X610X96 | 2300 | 24.01 | 1450 |
1170X570X96 | 2800 | 28.56 | 1720 |
1220X610X96 | 3100 | 31.89 | 1920 |
/ Primary Resistance & Face Velocity Diagram
![HAOAIRTECH gel seal hepa filter h14 with one side gasket for dust colletor hospital 14]()
/ Product Details
part.1
Hepa Air Filter With EVA Gasket and PU gasket
part.3
Mini-Pleats Media Compact
part.4
Air Filter Dust Detection Test
Application
Mini-pleats HEPA air filter suitable for hospital, electronic industry ,food,Pharmaceutical ,
bioengineering,precision instrument, electron semiconductors and dust-free room, national defense,aerospace field, fan filter unit, HEPA unit , air shower, dynamic pass box, dispensing booth ,softwall cleanroom, laminar flow booth and so on .
/ Our Service
Our Service
1: 100% scann air leaking test for each Mini-PleatsHEPA air flter, test report accompany all of
HEPA air filter.
2: 2 pcs in one carton .each air filter warp by PE Bag .
3: Small order is polywood packing so that we can send out by sea in LCL.
4: If order amount more than 20000USD, We accept the 100% LC at sight against with
document.
5: Free sample possible for you confirmation of quality .
/ package
Company Features1. Guangzhou HaoAir Purification Technology Co.,Ltd. does exports of hepa filter h14 to many countries on a basis of professional sales members and abundant know-how on trade business.
2. Every step, including product design, material selection, production and management, is tightly controlled in Guangzhou HaoAir Purification Technology Co.,Ltd..
3. HAOAIRTECH highly values details for whatever quality or service. Inquire online! It is a great goal for HAOAIRTECH to aim at being a hepa filter h12 supplier. Inquire online! HaoAir Purification will develop horizontally to meet the needs of foreign trade market. Inquire online!
