We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

HAOAIRTECH fast rolling air shower with automatic swing door for ten person 1
HAOAIRTECH fast rolling air shower with automatic swing door for ten person 2
HAOAIRTECH fast rolling air shower with automatic swing door for ten person 3
HAOAIRTECH fast rolling air shower with automatic swing door for ten person 1
HAOAIRTECH fast rolling air shower with automatic swing door for ten person 2
HAOAIRTECH fast rolling air shower with automatic swing door for ten person 3

HAOAIRTECH fast rolling air shower with automatic swing door for ten person

Brand:
Haoair
Model number:
HA-AS1200P Series
Material:
Coldrolled Steel with Baked Painting or Stainless steel 304/316
OEM /ODM:
OEM/ODM
Certificated:
CE,RoHS
Start port:
Guangzhou, Shenzhen, China port
Delivery time:
7-15 working days
MOQ:
1 unit
Country of Original:
China
Supply ability:
50-100 units per month
Payment term:
Western Union, T/T, L/C, D/P,D/A
Application:
Pharmacy Industry, Food Factory, Semi-conductor workshop
Inquiry




Introduction:
Air Showers is an equipment providing cleanliness for personnel, equipment and supply carts.
Nozzles jet out high-velocity and filtered air to remove stubborn particles from surfaces.

Configuration Features:
1.Microprocessor control system.
2.LCD display.
3.The air shower room duration time 0-99s adjustable.
4.Emergency button for emergency situation.
5.99.99%@0.3μm, efficiency can reach 99.99%@0.3μm with Pre filter and HEPA filter.
6.Unified specifications, easy to modify, can be customized per request.

Application:

Air shower is widely used in LCD and opto electronic display, PCB, microelectronics, dust-free coating, aseptic packaging, medical care, Pharmacy, auto glass and precision parts.

The air shower is approval by CE and RoHS certificate.
Customer’s design is available.

Air shower specification:


Clean room air shower HA-AS1200P Series

Model

HA-AS1200P1

HA-AS1200P2

HA-AS1200P3

Outer Si(mm) (WXDXH)

1200x1000x2180

1200x2000x2180

1200x3000x2180

Inner Size(mm)(WXDXH)

800x930x1910

800x1930x1910

800x2930x1910

Persons per cycle

1-2 person

2-4 person

3-6 person

Air shower duration

Factory set at 15 seconds (0-99 seconds adjustable)

Material

Coldrolled Steel with Baked Painting or Stainless steel 304/316

Fan consumption

0.75KWX1 set

0.75KWX2 sets

0.75KWX3sets

Air flow of fan(m3/h)

                  1300m3/h

Fan run (r/min)

2800r/min

Nozzle in stain less steel

     12 pcs

24 pcs

36pcs

Wind speed(m/s)

                        > 22-27m/s

Noise level(dB)

               <62dB

LED Fluorescent Lamp

20wx1

20wx2

20wx3





HEPA Filter

Size(mm)

630X630X69mm

Efficiency

99.99%@0.3um

Resistance

<220pa





Pre-filter

Size(mm)

785x385x21

Efficiency

75% @ 5um

Resistance

<30 Pa

Power supply

380V/50Hz



Air shower room product details:

HAOAIRTECH fast rolling air shower with automatic swing door for ten person 4

Customized clean room air shower photos:

HAOAIRTECH fast rolling air shower with automatic swing door for ten person 5










Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
