HAOAIRTECH clean room construction vertical laminar flow booth for sterile food and drug production

Company Advantages
1. The fabric of HAOAIRTECH clean room construction comes from reliable suppliers who have signed contracts with us for many years to ensure the best fabric quality.
2. Product quality in line with industry standards, and through the international certification.
3. HAOAIRTECH has received many praises from customers.

Class1000 Portable Softwall CleanRoom Booth

Applications:

Food industry, aerospace, life sciences, biotechnology, medical devices, plastic injection module, electronics assembly or hospital pharmacy

Operating Features:

1: The ceiling enables flexible placement of fan filter unit, the empty bays cover by powder coated steel panels.
2: the construction utilizing full welded, reinforced, steel tubular sections. The frame is finished with an abrasion-resistance oven-baked powder coat, it is free-standing not require any suspending ceiling supports
3: the PVC anti-static curtain door allowing for easy passage of material and personnel in and out of the clean area. The curtain terminated at a specific distance above the floor to allow for exhaust of clean air out of the clean room.
4: Control box can rapid start up the fan filter unit and lighting.
5: Fan filter unit is the energy efficient external rotor motor design reduces operating costs and has extremely low noise and vibration levels, improving the working conditions in the clean room.
6: the high quality mini-pleats HEPA filter utilizing an improved mini-pleated separation technique to maximize surface area improves efficiency and extends the filter life.

Product Specification:

MODEL	HA-LFB2000	HA-LFB3000	HA-LFB4000	HA-LFB5000
Ex size (mm) (W*D*H)	2000X2000X2596	3000X3000X2596	4000X4000X2596	5000X5000X2596
In size (mm)	1900x1900x2205	2900x2900x2205	3900x3900x2205	4900x4900x2205
Purification rank	Class10-300,000(FS209E USA)
HEPA filter	Efficiency : 99.99% @ 0.3um - 99.999% @ 0.12um (MPPS)
Pre-filter	Efficiency : 85% @ 5um
Control system	PC control system / promised speed by control box
Pressure Gauge	American Dywer pressure
Noise	<50-55 dB (test point distance is 1m)
Air velocity (m3/h)	0.2-0.5m/s Adjustable (test point distance is 30cm)
Frame material	stainless steel/steel with power coated/Cast aluminum profile
Wall frame	Tempered glass / PVC anti-static curtain (option)
Fan	EBM Fan /Taiwan fan/ Domestic fan (option)
Power suppler	AC110/220v 50HZ/60HZ

Basic Info:



Product Name	Softwall cleanroom/Softwall Modular Cleanrooms/Soft Wall Cleanroom
Brand	OEM/ODM
Material	SUS304,SUS201,SS304, Cold rolled plate
Size	Customized
MOQ	1 SET
Delivery Time	7-15 working days
Shipping Port	Guangzhou, Shenzhen, Shanghai
Warranty	2 years
Packing	Polywood packing
Payment	T/T,L/C, West Union, D/P, Cash

Company Features
1. It is greatly efficient for HAOAIRTECH to advance by paying attention to the R&D and manufacture of clean room construction .
2. We have a plant that is in compliance with internationally recognized standards of good manufacturing practices. It ensures that every product has the attributes of quality.
3. Our vision is to significantly improve customer satisfaction. We are working on a plan that assists specialists at the customer interface to gain fresh insights into customer needs and preferences, so as to ultimately create cost-effective values to customers. We take our responsibility to communities in which we work very seriously. We support local initiatives and local projects, particularly in the fields of the environment and education. We constantly strive to maintain our values, improve training and knowledge, with the aim of strengthening our leadership in this industry and our relationships with our customers and partners. Contact!
