secondary v rigid filter with gl interlocker frame for food and beverage

Company Advantages
1. v rigid filter is painstakingly created by a team of artisans.
2. The product has high load driving force. It is able to run smoothly under high pressure, overload, and other rigorous mechanical conditions.
3. The product does not have any unpleasant smell. During the production process, toxic flavor chemicals that produce unpleasant smells are completely removed.
4. This piece is a means of personal expression. It gives the wearer an opportunity to make a statement to the world about his or her sense of aesthetics and beauty.

Characteristics:

Dual density media reduces operating cost

Excellent performance in difficult operating conditions

High efficiency low resistance

Rigid metal construction

Deep pleats type water resistance glass fibre media

Turbulent air flow

Supported with aluminum foil clapboard

High temperature and high humidity

Intermittent exposure to water

Efficiency: MERV 14, MERV 13 and MERV 11 .



Operating conditions:

Media	Glass   Fiber
Frame	AL/GL   frame
Clapboard	Aluminum   Foil
Frame thickness (mm)	150/292mm
Screen	Metal   screen
Efficiency	F7/F8
Max Temperature	350 ˚F (177˚C)
Max Humidity	100%





Products Parameter：

Dimension   (mm) (W*H*D)	Rate Air   Flow   (m3/h)	Media   Area    (m2)	Dust   Holding    (g)	Rate   primary Resistance    (Pa)	Finally Resistance      (Pa)	Efficiency
289x594x150	675	4.3	261	<60	250-300	F6
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<80	300-400	F7
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<100	300-400	F8
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185



Application:

Commercial buidings, data centers , food and beverage, hospitality , industry , microelectronics

Healthcare , schools and universities ,pharmaceutical .

   Picture：

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. produces a variety of v rigid filter with outstanding features.
2. Guangzhou HaoAir Purification Technology Co.,Ltd. has many years of experience in high efficiency air filter development, research and production of scientific and technological personnel.
3. Commitment to excellence is our goal and what we pursue. We encourage every one of our employees to improve themselves and cultivate professional knowledge using our company's resources. Therefore, we are competent to provide targeted services to clients. Inquire! We are committed to corporate citizenship, social responsibility and world-class environmental, health and safety performance. The health and safety of its employees, contractors, and customers is always a top priority for the company. Inquire! Guangzhou HaoAir Purification Technology Co.,Ltd. constantly optimize the management and service system to promote better development. Inquire!
