Product Details
With the pursuit of excellence, HaoAir is committed to showing you unique craftsmanship in details.pass boxes, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.
Application Scope
The air showers developed by HaoAir is widely used in Manufacturing Industrial Parts Filter Supplies industry.With a focus on customers' potential needs, HaoAir has the ability to provide one-stop solutions.
Company Advantages1. HAOAIRTECH high temperature filter is produced with unique designs by our experienced experts.
2. The product is efficient at keeping out most sounds. The thick timber used in it has high density which can prevent the noise from getting in.
3. The product stands out for its durability. Adopting high-performance materials, its circuit board is protected from shocks, vibrations, abrasion, and harsh weather elements.
4. The product has won customers from all over the world.
Characteristics
Glass fibre with foil clapboard endure the high air volume in lower resistance at 0.3um particle
Especial high Temperature gasket can endure the 250℃ temperature continuous.
The aluminum or stainless steel frame for your choose.
High temperature glue prevent the air leaking in operation.
Adopting the laser to scan the filter one by one ( MPPS).
100 % provide the test report for each high temperature HEPA air filter
Filtration Efficiency: H13,H14,(EN1822). 99.5%-99.995%@0.3um
Applied to the special high temperature paint room or oven room
/ Products Parameter
Dimension(mm) (W*H*D) | Rate Air Flow
(m3/h) | Media Area
(m2) | Dust Holding
(g) | Rate primary Resistance
(Pa) | Finally
Resistance
(Pa) |
484X484X120 | 450 | 4.4 | 230 | H13 :<200Pa
H14 :<220Pa | 400-600pa |
610X610X120 | 700 | 7.1 | 370 |
610X915X120 | 1050 | 10.6 | 560 |
610X1220X120 | 1400 | 14.1 | 740 |
484X484X150 | 600 | 6.0 | 320 |
610X610X150 | 1000 | 9.7 | 510 |
610X915X150 | 1500 | 14.5 | 770 |
610X1220X150 | 2000 | 19.3 | 1020 |
484X484X220 | 1000 | 9.8 | 600 |
610X610X220 | 1600 | 15.8 | 920 |
610X915X220 | 2300 | 23.7 | 1340 |
610X1220X220 | 3000 | 31.6 | 1750 |
/ Primary Resistance & Face Velocity Diagram
/ Product Details
part.1
Aluminum foil clapboard
part.2
High Temperature Gasket
part.3
Red Color High Temperature Glue
part.4
Air Filter Dust Detection Test
Application
High temperature HEPA air filter suitable for filtration pharmaceutical factory, high temperature sterilizing tunnel or high temperature drying room produced tar, soot, dust and other particles.
/ Our Service
Our Service
1: 100% scan air leaking test for each HEPA air filter , test report accompany all of
HEPA air filter.
2: 1 pcs in one carton .each air filter warp by PE Bag.
3: Small order is plywood packing so that we can send out by sea in LCL.
4: If order amount more than 20000USD, We accept the 100% LC at sight against with
document
/ package
Company Features1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a huge producer of high temperature filter .
2. That every part of the high temperature air filter is strictly controlled more assures the exquisite performance of a product.
3. We have built up a strong company culture, such as active in social charity. We encourage employees to take part in local volunteer grant programs, and regularly donating capitals for the non-profit organization. Our value promising is based on innovative design, impeccable engineering, outstanding execution and quality service within budget and timelines. Contact! To embrace green production, we have adopted different plans. We will encourage reuse, recycle, and recovery of resources during production, which helps us decrease the amount of waste that ends up in the landfill. In the production stages, we make efforts in making full use of resources. We introduce cutting-edge machinery and facilities to reduce resources consumption, such as water, electricity, and product materials.
