We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 1
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 2
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 3
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 4
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 5
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 6
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 7
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 8
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 9
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 1
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 2
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 3
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 4
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 5
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 6
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 7
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 8
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 9

high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory

Brand:
HAOAIRTECH
Model number:
HA-HEPA-HT Series
OEM /ODM:
Yes
Certificated:
Rosh
Start port:
Guangzhou
Delivery time:
8 working days after we get the deposit.
MOQ:
10sets
Country of Original:
China
Supply ability:
set/one month
Payment term:
T/T , L/C , Western union
Application:
Worker in Clean room
Inquiry
Enterprise Strength
  • HaoAirtech adheres to the service concept to be customer-oriented. We are widely recognized in the market due to quality products and excellent services.
Product Comparison
HaoAirtech insists on the use of high-quality materials and advanced technology to manufacture air showers. Besides, we strictly monitor and control the quality and cost in each production process. All this guarantees the product to have high quality and favorable price.HaoAirtech's air showers has the following advantages over products in the same category.
  • high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 10
    v s
    high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 11
Company Advantages
1. The R&D of HAOAIRTECH high temperature filter bags is carried out by our professionals who have many years of experience in developing innovative mobile phone accessories.
2. This product is wear and tear resistant. The table-board and panel are made of wear-resistant materials which protect the surface of the product from the damage of heavy use.
3. This product is safe to use. Almost all potentially hazardous substances such as CPSIA, CA Prop 65, REACH SVHC, and DMF are tested and eliminated.
4. With the excellent properties, the market application of the product is rather positive.
5. We are able to provide complete service system from pre sales to after sales.



Characteristics
Working in the rat air flow the efficiency can reach 99.99%@0.3um
Glass fibre with foil clapboard endure the high air volume in lower resistance at 0.3um particle
Especial glass fibre gasket can endure the 350-450℃ high temperature continuous.
The stainless steel304 or 201 frame for your choose.
Black color high temperature glue prevent the air leaking in operation.
Adopting the laser to scan the filter one by one ( MPPS).
100 % provide the air leaking test report for each high temperature HEPA air filter
Filtration Efficiency: H12,H13,(EN1822). 99.5%-99.99%@0.3um
Applied to the special high temperature paint room or oven room
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 12



/ Products Parameter


Dimension(mm)
(W*H*D)

Rate Air Flow
  (m3/h)

Media Area
(m2)

Dust Holding
 (g)

Rate primar Resistance
  (Pa)

Finally Resistance
   (Pa)

484X484X120

450

4.4

230





H12<200Pa
  H13 :<210Pa







400-600pa

610X610X120

700

7.1

370

610X915X120

1050

10.6

560

610X1220X120

1400

14.1

740

484X484X150

600

6.0

320

610X610X150

1000

9.7

510

610X915X150

1500

14.5

770

610X1220X150

2000

19.3

1020

484X484X220

1000

9.8

600

610X610X220

1600

15.8

920

610X915X220

2300

23.7

1340

610X1220X220

3000

31.6

1750



/ Product Details



part.1
Aluminum foil clapboard
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 13

part.2
High Temperature Glass Fibre Gasket
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 14

part.3
Black Color High Temperature Glue
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 15

part.4
Air Filter Dust Detection Test
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 16


Application

High temperature HEPA air filter suitable for filtration pharmaceutical factory, high temperature sterilizing tunnel or high temperature drying room produced tar, soot, dust and other particles.



/ package


high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 17
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 18
high efficiency high temperature air filter with large air volume for filtration pharmaceutical factory 19




Company Features
1. Being a renowned manufacturer of high temperature filter bags , Guangzhou HaoAir Purification Technology Co.,Ltd. now enjoys a good reputation for its engagement in market research, designing, and manufacturing.
2. By using technology of industrial air filter , the efficiency and precision of high temperature air filter are greatly improved.
3. To win the favor of customers, HAOAIRTECH tries the best to serve the professional high temperature filter and considerate service. Get more info! HAOAIRTECH holds the tenet of customer service. Get more info! It is indispensable for HAOAIRTECH to develop its enterprise culture. Get more info!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
