HAOAIRTECH v rigid filter with abs frame for commercial buidings

Company Advantages
1. HAOAIRTECH ridgid air filter has a wide selection of design styles, enabling to fulfill the needs of the most demanding clients. The product creates a high cleanliness working environment
2. Rich in experience of manufacturing v rigid filter , Guangzhou HaoAir Purification Technology Co.,Ltd. is reliable supplier.
3. Customers can be assured of its quality and integrity. Automatic operation is the highlight of the product
4. This product has been tested by an independent third party. The product will greatly improve the quality of factory-made products
5. It can withstand the fierce competition of the market with the optimal quality. The product has passed strict air speed test

Characteristics:

Dual density media reduces operating cost

Excellent performance in difficult operating conditions

High efficiency low resistance

Rigid metal construction

Deep pleats type water resistance glass fibre media

Turbulent air flow

Supported with aluminum foil clapboard

High temperature and high humidity

Intermittent exposure to water

Efficiency: MERV 14, MERV 13 and MERV 11 .



Operating conditions:

Media	Glass  fiber with foil clapboard
Frame	Aluminium/ galvainzed frame
Clapboard	Aluminum   Foil
Frame thickness (mm)	120、150/292mm
Screen	Metal   screen
Efficiency	F6/F7/F8/ F9
Max Temperature	350 ˚F (177˚C)
Max Humidity	100%





Products Parameter：

Dimension   (mm) (W*H*D)	Rate Air   Flow   (m3/h)	Media   Area    (m2)	Dust   Holding    (g)	Rate   primary Resistance    (Pa)	Finally Resistance      (Pa)	Efficiency
289x594x150	675	4.3	261	<60	250-300	F6
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<80	300-400	F7
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<100	300-400	F8
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185



Application:

Commercial buidings, data centers , food and beverage, hospitality , industry , microelectronics

Healthcare , schools and universities ,pharmaceutical

  Picture :

1: Galvanized material frame in interlocker style :                    2: Both side is flange without any screw。

3: Both side is metal screen with one bard for endure high air volume.
