HAOAIRTECH ulpa filter with hood for dust colletor hospital

Company Advantages
1. HAOAIRTECH hepa air cleaner follows the complete design processes. Its design processes include frame design, drive systems design, mechanisms design, bearing selection, and sizing.
2. The product features reliable operation. It has an advanced electrical system that is equipped with overvoltage, overcurrent, and overheating protection.
3. The quality of ulpa filter can be proved by our sample testing.

Heap air filter with paper clapboard adopt the special design to keep the space between pleated layers by clapboard. Paper spacers can accurately maintain the distance between the pleat layers, Maximum use of filter material under minimum resistance.

Media	Super glass fibre
Frame	AL/GL/MDF frame
Gasket	Neoprene /EVA or PU
Media    spacer	Hot melt
Frame thickness    (mm)	120/150/220
Clapboard	120g/m paper
Efficiency	99.99%-99.999%@0.3um
Max    Temperature	80℃
Max    Humidity	80%

Dimension(mm)      (W*H*D)	Rate    Air Flow (m3/h)	Media  Area (m2)	Dust  Holding (g)	Rate primary Resistance(Pa) (H13-H14)	Finally Resistance   (Pa)
484X484X120	450	4.4	230	220Pa	400-600pa
610X610X120	700	7.1	370
610X915X120	1050	10.6	560
610X1220X120	1400	14.1	740
484X484X150	600	6	320
610X610X150	1000	9.7	510
610X915X150	1500	14.5	770
610X1220X150	2000	19.3	1020
484X484X220	1000	9.8	600
610X610X220	1600	15.8	920
610X915X220	2300	23.7	1340
610X1220X220	3000	31.6	1750

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. has been a renowned Chinese manufacturer of ulpa filter . We differentiate ourselves by providing innovative products.
2. Owning a team of excellent customer service is the key factor in our success. They are highly skillful in promoting effective communication and getting along well with customers from different backgrounds. They are absolutely the business ambassadors for our company.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. has established a perfect sales and service network throughout the world. Ask! The corporate mission of Guangzhou HaoAir Purification Technology Co.,Ltd. is to hepa air cleaner . Ask! We will continue to provide service with the tenet of hepa room filter . Ask!
