HAOAIRTECH stainless steel pass box clean room with conveyor line for cargo

Company Advantages
1. The production of HAOAIRTECH wall pass through box involves the following processes: the cutting of wall panels, primary steel fixings, steel beam clamps, and the fabrication of aluminum track. A sample of the product can be offered for the confirmation of quality
2. Some of our customers say it is worthy because it fits perfectly their lifestyle, washing, cooking, as well as storage habits. The product dedicates to keeping a cleanliness class of 10000-300000
3. The product features frost resistance. Since it can resist freezing or thawing, it won't lose its strength in freezing and become brittle. It highly conforms to the dustless workshop management standard
4. This product has good rebound performance. The cushioning pad used is very soft and elastic, offering support and buffering to the foot. The product is reputed for its long service life

Vertical Slide Door Air Shower Pass Through

PLC Control Logic For Air Shower Pass Through:

 Sensor1 +Front Vertical Slide Door 1 + Haoairtech Auto Conveyor Line+ Sensor 2+Air Shower Pass Box+Back Vertical Slide Door2 + Sensor 3



 Sensor1:  This sensor should be fix on  auto conveyor line at end postion next to vertical front door 1

 Sensor 2:  This should be fix inside of air shower pass box.

 Sensor 3:  This should be fix on auto conveyor line next to back vertical slide door 2 .



1: When the carton pass the sensor 1 , the system will be give single to door. so that front vertical slide door open. meanwhile the keling auto conveyor line start working .

 2: When the carton pass the sensor 2 , system will be make the front door closed, and both door interlocker ,the self-clean system begain working (0-60S) adjustable .

 3: after the self-clean system finshed, the back side vertical slide door 2 will be opened , the system will be give singe to keling auto conveyor and yourself auto conveyor line start working ,

 4: when the carton pass the sensor 3 . the system remind the vertical slide door2  closed and keling conveyor line stop working.



 Note :



1: when the carton1 still inside the pass box , or still not pass the sensor3,  if there are new carton arrived sensor1, the system can not give any single to front door, untill the carton1 pass the  sensor 3 .

Parameter:



MODE	Air Shower   pass box with PLC control system
External size	1000x8000x2285 mm
Internal size	600X600x500mm
Air speed	>25m/s
Noise (dB)	75Db
Nozzle	8pcs
Filtration   Step	H13  99.995%@0.3um EU3  75%@2um
Fan	1 Sets (0.75KW 380V/50HZ    )
Booth Locker	Electric interlocker
Door	Entrance and   Exit door is automatic vertical glass   slide door
PLC Control   box	1 set

PLC Control Box :
