HAOAIRTECH professional rigid filter with abs frame for industry
1. Fine workmanship: HAOAIRTECH ridgid air filter is crafted by skillful and experienced workers who aim at producing high quality products and use their skills to perfect the product.
2. The product has a long operation life and can be held up for a long time. Thus, it is proved that this quality product has won high recognition in the market for its durability.
3. Quality assurance review is one of the critical steps in producing rigid filter in HAOAIRTECH.
Characteristics:
Dual density media reduces operating cost
Excellent performance in difficult operating conditions
High efficiency low resistance
Rigid metal construction
Deep pleats type water resistance glass fibre media
Turbulent air flow
Supported with aluminum foil clapboard
High temperature and high humidity
Intermittent exposure to water
Efficiency: MERV 14, MERV 13 and MERV 11 .
Operating conditions:
Media | Glass Fiber |
Frame | AL/GL frame |
Clapboard | Aluminum Foil |
Frame thickness (mm) | 150/292mm |
Screen | Metal screen |
Efficiency | F7/F8 |
Max Temperature | 350 ˚F (177˚C) |
Max Humidity | 100% |
Products Parameter：
Dimension (mm) (W*H*D)
| Rate Air Flow (m3/h) | Media Area (m2) | Dust Holding (g) | Rate primary Resistance (Pa) | Finally Resistance (Pa) | Efficiency |
289x594x150 | 675 | 4.3 | 261 |
<60 |
250-300 | F6 |
594x594x150 | 1385 | 8.84 | 354 | |||
287x594x292 | 1490 | 9.52 | 571 | |||
594x594x292 | 3085 | 19.7 | 1185 | |||
289x594x150 | 675 | 4.3 | 261 |
<80 |
300-400 | F7 |
594x594x150 | 1385 | 8.84 | 354 | |||
287x594x292 | 1490 | 9.52 | 571 | |||
594x594x292 | 3085 | 19.7 | 1185 | |||
289x594x150 | 675 | 4.3 | 261 |
<100 |
300-400 | F8 |
594x594x150 | 1385 | 8.84 | 354 | |||
287x594x292 | 1490 | 9.52 | 571 | |||
594x594x292 | 3085 | 19.7 | 1185 |
Application:
Commercial buidings, data centers , food and beverage, hospitality , industry , microelectronics
Healthcare , schools and universities ,pharmaceutical .
Picture：
Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a leading company in China to export rigid filter .
2. We have experienced machine operators. They operate our manufacturing facilities under strict environmental controls to ensure our conditions meet our customer’s and regulatory requirements.
3. Except for high quality, Guangzhou HaoAir Purification Technology Co.,Ltd. also provides customers with professional service. Contact us! HAOAIRTECH has been exerting itself to being an experienced and technical rigid cell filter supplier. Contact us! We aim to be an international compact rigid filter exporter. Contact us!
