HAOAIRTECH Pleated Air Filter with metal frame for central air conditioning and centralized ventilation system

Company Advantages
1. HAOAIRTECH Pleated Air Filter is produced by state-of-the-art precision machines.
2. Its service life is highly guaranteed by the strict test procedure.
3. The product has a competitive advantage in quality and price.
4. This product has considerable practical and commercial value.



Introduce:

     Pleats filter is suitable for primary filtration of air conditioning system. and Medium efficiency air filtration.  It is mainly used to filter dust particles above 5 micron. Outer frame materials include cardboard frame, Aluminium frame and galvanized iron frame.

   Filter materials include non-woven fabric, nylon mesh, activated carbon filter material, metal mesh, Protective mesh includes double-sided plastic-sprayed wire mesh and double-sided galvanized wire mesh.

Media	Non-Woven fabric and synthetic fiber
Frame	AL/GL/SUS201/304  frame
Gasket	Neoprene / EVA or PU
Frame size	24/48/96mm
Screen	Metal   screen in one side or both side
Efficiency	G1-G4 ,F5-F8
Max Temperature	80℃
Max Humidity	100%

Dimension	Rate air flow	Media area	Dust Holding(g)	Initial Resistance (pa)	Finally Resistance (pa)	Efficiency
592x592x46	2600	0.97	110	<25	100-200	G1
			130	<30	100-200	G2
			160	<40	100-200	G3
			200	<45	150-200	G4
592x490x46	2200	0.81	98	<25	100-200	G1
			110	<30	100-200	G2
			130	<40	100-200	G3
			160	<45	150-200	G4
592x287x46	1300	0.48	50	<25	100-200	G1
			60	<30	100-200	G2
			80	<40	100-200	G3
			100	<45	150-200	G4

Customer size is available

mainly used for: central air conditioning and centralized ventilation system pre-filtration, large- scale air compressor pre-filtration, clean return air system, pre-filtration of local high efficiency filter device.

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a Pleated Air Filter producer known for high quality.
2. We have successfully cooperated with some internationally renowned brands. They are quite satisfied with the products we served. This proves that we can and we have the qualification to stand out in the international markets.
3. Guangzhou HaoAir Purification Technology Co.,Ltd.'s ongoing business concept is pleated filter . Get an offer! A central tenet of Guangzhou HaoAir Purification Technology Co.,Ltd. could be summarized as z line filter . Get an offer! Guangzhou HaoAir Purification Technology Co.,Ltd. ensure pleated furnace filters service for its costumers. Get an offer!
