HAOAIRTECH plc control pass box clean room with baked painting for hvac system

Company Advantages
1. The design of HAOAIRTECH pass box clean room is the perfect combination of aesthetics and practicality.
2. The product has excellent strength and hardness. Constructed of heavy-duty welded metal, its structure is too tough to be deformed.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. implements a strict internal quality control system to reward customers with superior quality.

SS316 Dynamic Pass Box

Product Characteristic :

      SS316 Dynamic Pass Box is designed to allow material transfer through controlled environment without much personnel movement to minimize man /

material movement & avoid cross contamination between different classified areas. This is essentially installed to minimize movement of personnel

for transfer of material into and from the clean room. It aids to achieve desired classification, maintain integrity of products, process & controls ingress

of particulate contaminants into clean room & between different classified areas. Our range of Dynamic pass boxes is available in various specifications

as per the client’s requirements.Dynamic Pass Box is with a variety of standard dimensions also our pass boxes can be custom engineered to any size.

Dynamic pass boxes available in powder coated Mild Steel, SS 304 / 316 / 316L or a combination of both.

Optional Accessories:

 1: U.V. Light with Hour MeterElectro-Magnetic

  2: Mechanical InterlockingSS 316 removable grills on side walls for return air Floor mounted

 3: construction with three side wall structure

 4: Door Drop SealAudio Visual Alarm indicating condition of HEPA FiltersClean

 5: down timer with operation hold indicatorVFD based control systemsPhotohelic guage

 6:  Digital pressure gauge to monitor of pressure drop across filterFlame Proof Fitting

SS316 Dynamic Pass Box Products Parameter:

MODEL	HA-DPB500
External size (mm) (W*D*H)	700x570x1050mm
Work zone (mm) (W*D*H)	500x500x500mm
Purification rank	Class 100
Material  （Option）	1: Entirety Sus304.(T=1.2/1.5mm) 2: Entirety sus201. (T=1.2/1.5mm) 3: External is steel with power coated, Internal is SUS304(T=1.2/1.5mm) 4: External is steel with power coated. Internal is SUS201(T=1.2/1.5mm)
Control system	1: Gel Sealant mini-pleats HEPA air filter so that pass the DOP test without any problem. 2: Pass Box inside bottom corner is round shape without any dust accumulation .  3: Double layer vacuum glass have very good appearance  4: Software computer interlocking door with long time using life  5: Air speed is 0.45m/s adjustable
UV light	1 PCS
Power supply	220v/50HZ
packing size (mm)	800x870x1300mm
Packing material	Standard Export Poly wood Packing(Fumigant free material)

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a leading enterprise of the modern pass box clean room manufacturing industry in China.
2. We have invested heavily in new technology and our facilities. All our in-house machines are equipped with ground-breaking technology to maximize productivity and reduce waste.
3. Our business philosophy is to pro-actively corporate with our suppliers that comply with ethical practices and help our customers find innovative and timely solutions. We aim to be transformative and adaptive. We absorb and recognize the client's aspiration and translate it into a vision; a vision that culminates in the interaction of different design elements that work in synergy to create a product that is not only excellent but also contributive. Putting the customer at the center of everything we do is a priority for us. We maintain trust by striving to provide our high-quality products and deliver excellent services. We love taking care of our customers and take great pleasure in their satisfaction. Each and every customer is given a great deal of care and consideration. Contact us!
