HAOAIRTECH pass box clean room with baked painting for hospital

Company Advantages
1. HAOAIRTECH static pass box specification is creatively designed to help customers break into the fast-growing market. The product will greatly improve the quality of factory-made products
2. Guangzhou HaoAir Purification Technology Co.,Ltd. puts customer satisfaction at the first place. The product creates a clean environment to reduce allergy and asthma symptoms
3. The product is not only functional but also durable, with a longer service life compared with other competitive products. The product prevents viruses and bacteria from spreading
4. The product is tested on numerous quality parameters before supplying to patrons With premium quality, the product is also fit for working under difficult operating conditions

Design Dynamic Pass Box

   Features:

• ISO/CE certified

• Interlocking system

• UV light with Timer

• Magnehelic

• gauge

• Low noise less than 60db

• SS construction for chemical and rustproof

• Buzzer indication for material transfers

• The magnetic locking system on doors

    We design dynamic pass box equipment in complete Stainless steel 304 with an interlocking system, UV light, Illumination light, Fan Motor, 0.3 microns HEPA filter & pre-filters. Hepa Filters are suction filters made as per European standards to prevent any kind of cross-contamination. The interlocking system will give the advantage of opening one door at a time during the pass-through of material. Class 100 & Class 1 cleanroom users always prefer a dynamic pass box instead of a static pass box.

Products Parameter：

Model	HA-DPB
Design type	Dynamic
Cleanliness level	Class 100
Internal Dimension	2 x 2 x 2 Ft. 3 x 3 x 3 Ft. 4 x 3 x 3 Ft.
Construction	SS 304
Illumination	Philips LED
Air system	MS Blower
Filters	The HEPA filter (99.97%)0.3 microns-filters (95% down to 5 microns)
Door	Interlocking Doors with Glass view Window
Standard Fittings	Light indicators for door Handles & hinges UV light
Power supply	220 V +/- 10%  ,  50/60 Hz



Applications: Pharmaceutical Industries, Food Processing Industry. Semiconductor Industry, Chemical Laboratories, Electronics Industry

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is solid and strong for its technology foundation.
2. Being dedicated to providing pass box clean room solutions for users with our best service attitude is something HAOAIRTECH has been always doing. Ask online!
