We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

HAOAIRTECH non standard modular cleanroom with ffu online 1
HAOAIRTECH non standard modular cleanroom with ffu online 2
HAOAIRTECH non standard modular cleanroom with ffu online 1
HAOAIRTECH non standard modular cleanroom with ffu online 2

HAOAIRTECH non standard modular cleanroom with ffu online

Brand:
HAOAIRTECH
Model number:
HA-LFB
Material:
Steel with power coated
OEM /ODM:
OEM/ODM
Certificated:
CE
Start port:
GUANGZHOU
Delivery time:
10 working days after we get the deposite
MOQ:
1sets
Country of Original:
China
Supply ability:
100set/month
Payment term:
100%T/T in advance ,100% LC at sight against with document
Application:
Semiconductor cleanroom
Inquiry
Product Name
vertical laminar flow booth
Other Name
Clean Booth
Guarantee Time
12 months
Purificaiton Rank
ISO7/ISO8
Dimension
3000X2500X2590mm
Power Supplier
220V/50HZ OR 60HZ
Company Advantages
1. The inspection of HAOAIRTECH cleanroom design and construction involves precision measurement. It is tested to comply with international medical standards and regulations. The product prevents viruses and bacteria from spreading
2. This product provides opportunities for significant reductions in building energy use and CO2 emissions, while at the same time having a positive impact on the quality of the indoor environment. Made of stainless steel SUS304, it is beautiful and durable
3. The product is renowned for its high energy efficiency. This product consumes little energy or power to finish its task. The product creates a clean environment to reduce allergy and asthma symptoms

Vertical Laminar Flow Clean Booth



ntroduce:

Haoairtech designed this as a portable solution to create a Class 10-100000  vertical laminar flow clean room environment without the high cost and constraints of a hard wall system. It's affordable, reliable, energy efficient and easy to assemble as well as disassemble.

The prefabricated wiring system makes electrical hook-up simple with factory wired components and leg-mounted on/off switches for lights and filters. A single point electrical hook-up or heavy duty line cord (under 15 amps) are provided, which may eliminate the need for an expensive installation.


Product Features:

Purification Rank : Class10-class 10000
Fan filter unit with mini-pleats HEPA filter/ULPA filter( 99.995%@0.3um )


vertical laminar flow Clean Booth Control Box Function:

A: Control the power on/off

B: Control the fan filter unit air speed UP/Down

C: Control working area purification light

D: Control the UV light in working area

E: Monitor differential gauge so that replacement HEPA filter in time.

Material: stainless steel 304 or steel with milk color powder coated

Pressure Relief valve base one request


Products Parameter

Item

Vertical Laminar Flow Clean Booth

Purification Rank

Class to class 100.000

Dimension L*W*H

According client request

Fan Filter Unit

Dimension

2x2,2x4,4x4 optional

Structural Material

Stainless steel, aluminum alloy, AI-Zn plate

Power Supply

220V/50HZ AC

Air Filter

Mini-pleats HEPA /ULPA Air filter

Frame Material

Aluminum alloy/stainless steel201/304

Wall Material

Acrylic /sandwich panel/anti-static acrylic

Ceiling

Aluminium –plastic panel , sandwich panel

Air Conditioner

Constant temperature air conditioning
Or Constant temperature and humidity air conditioning

Lighting

LED light or T5 (Optional )

Air Shower

Optional

Pass Box

Optional

Air Flow Floor

Optional


Note:

We have a wide range of configuration available to meet most cleanroom booth standards up to Class 10/ISO Class 4. For Class 10/ISO Class 4 and Class 100/ISO Class 5 cleanliness level, 100% laminar airflow is essential to prevent any deterioration of cleanliness caused by the present of non-laminar airflow. At this cleanliness level, the ceiling must be totally covered by HEPA/ULPA filter and the lighting is usually tear-drop. As the result, all particles come from the personnel , processes and equipment are immediately swept away from the clean area.

Where the ceiling is not fully covered, turbulent zones are present. In this cases, particles introduced or present in the clean area are re-circulated and produce temporary deterioration of the cleanliness level.

HAOAIRTECH non standard modular cleanroom with ffu online 3


Company Features
1. We have advanced manufacturing facilities. This allows us to place the highest level of attention to quality control throughout the production process, from start to finish.
2. HAOAIRTECH always stress the importance of high quality service. Get info!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
