HAOAIRTECH laboratory portable laminar flow hood for optoelectronic industry

Company Advantages
1. HAOAIRTECH horizontal laminar flow hood is made employing advanced technology and sophisticated crafts. The product assures an extremely high-efficient manufacturing process
2. People can benefit a lot from this product. It helps reduce leak and a reduction of mechanical failure, which directly contributes to the saving on cost. The product stands out for its high efficiency for purification
3. The products conform to strict quality standards. The product prevents viruses and bacteria from spreading
4. This product has been recognized by industry experts for its excellent performance. It acts as an indispensable part in a dustfree production line

Laminar air flow hood provide operator, process and product protection by utilizing HEPA filtered unidirectional laminar air flow booth  to maintain an ISO5 environment at rest within the work zone and capture particulates during open handling processes .

MODEL	HA-DB1000	HA-DB1500	HA-DB2000
External size (mm)      (W*D*H)	1200x1500x2400mm	1500x1700x2400mm	2000x1800x2400mm
Work zone (mm)      (W*D*H)	1100x1200x2000mm	1400x1200x2000mm	1900x1300x2000mm
Purification rank	Class 100(ISO5)
Air speed	0.45m/s +_20%
Material（Option）	1: Entirety Stainless Steel 201/304/316.(T=1.2/1.5mm) 2: External and internal side is steel    with power coated. (T=1.2/1.5mm)
Control system	1: LCD touchable screen display with air    speed adjustable and constant temperature and constant humidity data check. 2: Gel Sealant High Efficiency HEPA air    filter for high purification rank 3: Wind speed detection, Constant    temperature and constant humidity Detector according to client request install    .  4: DOP/PAO Port and differential Pressure    Guage for HEPA /secondary filter so that remind of you change the air filter    in time 5: 5 different filter configuration    available utilizing combination of G4,F8.H13,H14 and PLF Screens . 6; GMP Modular design with minimized    joints and seams. 7: Four side corner and corner line is circle    design prevent dust accumulation
Noise level(dB)	<65dB
Filter step	3 Step
HEPA filter	99.995% @ 0.3um Gel sealant mini--pleats HEPA Air Filter
Secondary filter	F8 pocket air filter
Pre-filter Efficiency	G4 Z-Line panel air filter
Power supply	380V/50HZ  OR 220V/50HZ
Packing    material	Standard Export Poly wood Packing(Fumigant free material)

Weighting booth is designed such that through the different configurations it can be applied  but not limited to the follow field : food ,electronic, robotic, nutraceutical, animal , cosmetic , biological , and pharmaceutical .

/ Certificated

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. has an unrivalled competitive edge in manufacturing horizontal laminar flow hood . We are widely accepted in the industry. We now have more overseas customers to cooperate with us. Thanks to the strong sale team who devote themselves to explore and open various marketing channels in different regions and countries.
2. Covering a large area, our factory allows for the storage of our raw materials. This reduces the time spent on the preparation of materials, minimizing delays and finishing orders ahead of schedule.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. has domestic first-class designers, excellent technical staff and management personnel. Guangzhou HaoAir Purification Technology Co.,Ltd. has only one boss who is our every customer, and we all work for our customers. Inquire online!
