HAOAIRTECH laboratory portable laminar flow hood clean benches for biology horizontal

Company Advantages
1. The raw material used in HAOAIRTECH laminar flow hood price is procured from some of the reliable vendors.
2. This product will always provide the consistency required. It is programmed for precise and repetitive motion, so it's not so easy to make mistakes.
3. People can be assured that the product can keep its appearance excellent and it will not shrink or out of shape after washing.
4. This piece of clothing will help the wearer to stand out from the crowd and appear more presentable than others.

Introduction

Horizontal laminar flow bench is a kind of local purification table with strong versatility.
It has less noise and outward wind direction. It is commonly used in the electronic industry.
The advantage of horizontal laminar flow bench is that it is open and has no protective baffle.
It is convenient to operate and take goods. It can effectively improve work efficiency, but it can not work on products harmful to human body, because it will be harmful to operator's health.



Characteristic
1.Seismic isolation working table.
2.Door glass adopts push-pull up and down type, which has novel structure and is easy to observe.
3.In the protection of clean air flow, the pollution of articles can be effectively prevented.
4.Suitable for variable air supply system with high and low wind speed.
5.Adjustable, reliable operation, low consumption and energy saving. It can be equipped with lighting and sterilization system.
6.Digital display control interface, more humanized design.
7.Universal casters can be freely movable, flexible and convenient

Design drawings

1.control board    2.power cable   3.purification light    4.pressure indication 5.HEPA air filter
6.Antistatic acrylic plate  7.socket  8.fan   9.pre-filter  10.wheel

Technical parameter

MODEL	HA-HCB-1	HA-HCB-2	HA-HCB-3
External size (mm)	960x780x1580	1200X820X1580	1500X900X1580
(WXDXH)
Work zone (mm)	930x600x650	1180x600x650	1480 x600x650
(WXDXH)
Purification rank	FS209E 100Rank
Rating airflow(m3/h)	1200m3/h	1800m3/h	2300m3/h
Filtration efficiency	More than 99.99%@0.3um H13-H14
Average wind speed	0.3-0.6m/s Adjustable
Intensity of illumination	>300lx
Fluorescent lamp	20Wx1	30WX1	40WX1
Material	1:Entirety Sus304/201
(Option)	2:External is steel with power coated, Internal is SUS304
	3: External is steel with power coated. Internal is SUS201
Control board	1: Control the air speed up/down
	2: Power off /on
	3: Working time display
	4: Working area light on/off
	5: Alarm indicator
Power	280W	405W	490W
Noise	<65dB
Power supply	220V-240V AC 50HZ
Packing size	1160x980x1780mm	1400x1020x1780mm	1700x1100x1780mm
