We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.
HAOAIRTECH interlocking dynamic pass box validation with conveyor line for electronics factory
1. HAOAIRTECH dynamic pass box validation is manufactured using high quality raw materials which are safe and eco-friendly. The product can be used to save time for cleaning and vacuuming
2. Guangzhou HaoAir Purification Technology Co.,Ltd. has formed stable sales market and ripe sales channel for pass box . The product stands out for its high efficiency for purification
3. pass box shows good comprehensive properties performance. The product is reputed for its long service life
4. With all its features like dynamic pass box validation , pass box is conducive to popularization and application. The product creates a clean environment to reduce allergy and asthma symptoms
One row hole on the top door so that the purification air was force out of clean room.
External size: 760*670*690mm
Internal size: 600*600*600mm
External Material: stainless steel304 (t=1.2)
Inside Material: stainless steel304 (t=1.2)
Double layer vacuum glass
Mechanical interlocking
MODEL | HA-PPB500 | HA-PPB600 | HA-PPB700 |
External size (mm) | 660x500x590mm | 760x600x690mm | 860x700x790mm |
Work zone (mm) | 500x500x500mm | 600x600x600mm | 700x700x700mm |
Material （Option） | 1: Entirety Sus304.(T=1.2/1.5mm) | ||
Control system | 1: Both door is mechanical interlocking | ||
UV light | 1 PCS | ||
packing size (mm) | 800x780x850mm | 910x880x940mm | 1100x980x1050mm |
Packing material | Standard Export Poly wood Packing(Fumigant free material) | ||
Introduce
The special design of the negative pressure pass box to form a pressure difference between the positive pressure of the clean room and the negative pressure in contaminated area, it forces the air flow direction from the clean area to the contaminated area always. In this flow process, pass box inside dust on the cargo and the suspended particles in the air are taken away to achieve the possibility of completely avoiding cross contamination. four side inner arc design proved the dust accumulation, Overall seamless connection soft PU Foam gasket have very goods performance in eliminate air leaking problem.
Our Service
1：Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. has developed rapidly over the years and has grown into a leader in pass box field. HAOAIRTECH has successfully established a design center, a standard R&D department, and an engineering department.
2. The dynamic pass box production technology has brought more benefits for HAOAIRTECH.
3. To better ensure the perfect quality of pass through box, HAOAIRTECH has been constantly improving the technology. Favored by more customers, HAOAIRTECH is very confident to be a lead of pass box clean room industry. Inquire online!
