Company Advantages1. The raw materials of HAOAIRTECH system booth are carefully chosen. The production process of these materials are strict and their quality reaches the international standards, which helps it withstand the test of the time. The product is widely used for high-end clean rooms of various manufacturers
2. This piece of furniture will not only fit perfectly into people's space but will also provide much-needed versatility. The product prevents viruses and bacteria from spreading
3. Production practice shows that weighing booth is more practical in system booth with good effect, long service life and low cost. The product creates a high cleanliness working environment
Product Features
Negative Pressure Laminar Flow
GMP Modular design with minimized joints and seams.
5 different filters configuration available utilizing combination of G4,F8.H13,H14
and PLF Screens .
Gel sealant HEPA Air Filter(99.995%@0.3um) for high purification rank
Purification rank: Class100 /ISO5
Air speed: 0.45m/s+_20%
10% Exhaust air leaking (Adjustable)
/ Products Parameter
MODEL | HA-DB1000 | HA-DB1500 | HA-DB2000 |
External size (mm)
(W*D*H) | 1200x1500x2400mm | 1500x1700x2400mm | 2000x1800x2400mm |
Work zone (mm)
(W*D*H) | 1100x1200x2000mm | 1400x1200x2000mm | 1900x1300x2000mm |
Purification rank | Class 100(ISO5) |
Air speed | 0.45m/s +_20% |
Material(Option) | 1: Entirety Stainless Steel 201/304/316.(T=1.2/1.5mm) 2: External and internal side is steel with power coated. (T=1.2/1.5mm) |
Control system | 1: Air Speed according to frequency converter control . 2: Gel Sealant High Efficiency HEPA air filter for high purification rank 3: Wind speed detection, Constant temperature and constant humidity Detector according to client request install 4: DOP/PAO Port and differential Pressure Guage for HEPA /secondary filter so that remind of you change the air filter in time 5: 5 different filter configuration available utilizing combination of G4,F8.H13,H14 and PLF Screens . 6; GMP Modular design with minimized joints and seams. 7: PVC strip curtains available 8; Energy Efficient high air volume fan to minimize operating cost, |
Noise level(dB) | <65dB |
Filter step | 3 Step |
HEPA filter | 99.995% @ 0.3um Gel sealant mini--pleats HEPA Air Filter |
Secondary filter | F8 pocket air filter |
Pre-filter Efficiency | G4 Z-Line panel air filter |
Power supply | 380V/50HZ OR 220V/50HZ |
Packing material | Standard Export Poly wood Packing(Fumigant free material) |
/ Specification
![HAOAIRTECH hihg efficiency weighing booth manufacturer for dust pollution control 10]()
/ Product Details
Application
Dispensing booth is designed such that through the different configurations it can be applied but not limited to the follow field : food ,electronic, robotic, nutraceutical, animal , cosmetic , biological , and pharmaceutical .
/ Certificated
![HAOAIRTECH hihg efficiency weighing booth manufacturer for dust pollution control 14]()
/ Our Service
Our Service
1:Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
Company Features1. Guangzhou HaoAir Purification Technology Co.,Ltd. plays a leading role in the scientific research and technological strength
2. Quality service ensures that we maintain the leadership position in weighing booth industry.
