We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

HAOAIRTECH high efficiency cleanroom systems with constant temperature and humidity controlled for sterile food and drug production 1
HAOAIRTECH high efficiency cleanroom systems with constant temperature and humidity controlled for sterile food and drug production 2
HAOAIRTECH high efficiency cleanroom systems with constant temperature and humidity controlled for sterile food and drug production 1
HAOAIRTECH high efficiency cleanroom systems with constant temperature and humidity controlled for sterile food and drug production 2

HAOAIRTECH high efficiency cleanroom systems with constant temperature and humidity controlled for sterile food and drug production

Brand:
HAOAIRTECH
Model number:
HA-LFB
Material:
Steel with power coated
OEM /ODM:
OEM/ODM
Certificated:
CE
Start port:
GUANGZHOU
Delivery time:
10 working days after we get the deposite
MOQ:
1sets
Country of Original:
China
Supply ability:
100set/month
Payment term:
100%T/T in advance ,100% LC at sight against with document
Application:
Semiconductor cleanroom
Inquiry
Product Name
vertical laminar flow booth
Other Name
Clean Booth
Guarantee Time
12 months
Purificaiton Rank
ISO7/ISO8
Dimension
3000X2500X2590mm
Power Supplier
220V/50HZ OR 60HZ
Company Advantages
1. The shapes and colors of cleanroom systems can be customized based on customer's requirements. The product is widely used for high-end clean rooms of various manufacturers
2. The product is gaining larger market clout and wider application. The product stands out for its high efficiency for purification
3. This product has been tested for good performance and durability. Made of stainless steel SUS304, it is beautiful and durable
4. Products must be inspected by our inspection system to ensure that the quality meets industry requirements. The product can maintain high air quality of the factory

Vertical Laminar Flow Clean Booth



ntroduce:

Haoairtech designed this as a portable solution to create a Class 10-100000  vertical laminar flow clean room environment without the high cost and constraints of a hard wall system. It's affordable, reliable, energy efficient and easy to assemble as well as disassemble.

The prefabricated wiring system makes electrical hook-up simple with factory wired components and leg-mounted on/off switches for lights and filters. A single point electrical hook-up or heavy duty line cord (under 15 amps) are provided, which may eliminate the need for an expensive installation.


Product Features:

Purification Rank : Class10-class 10000
Fan filter unit with mini-pleats HEPA filter/ULPA filter( 99.995%@0.3um )


vertical laminar flow Clean Booth Control Box Function:

A: Control the power on/off

B: Control the fan filter unit air speed UP/Down

C: Control working area purification light

D: Control the UV light in working area

E: Monitor differential gauge so that replacement HEPA filter in time.

Material: stainless steel 304 or steel with milk color powder coated

Pressure Relief valve base one request


Products Parameter

Item

Vertical Laminar Flow Clean Booth

Purification Rank

Class to class 100.000

Dimension L*W*H

According client request

Fan Filter Unit

Dimension

2x2,2x4,4x4 optional

Structural Material

Stainless steel, aluminum alloy, AI-Zn plate

Power Supply

220V/50HZ AC

Air Filter

Mini-pleats HEPA /ULPA Air filter

Frame Material

Aluminum alloy/stainless steel201/304

Wall Material

Acrylic /sandwich panel/anti-static acrylic

Ceiling

Aluminium –plastic panel , sandwich panel

Air Conditioner

Constant temperature air conditioning
Or Constant temperature and humidity air conditioning

Lighting

LED light or T5 (Optional )

Air Shower

Optional

Pass Box

Optional

Air Flow Floor

Optional


Note:

We have a wide range of configuration available to meet most cleanroom booth standards up to Class 10/ISO Class 4. For Class 10/ISO Class 4 and Class 100/ISO Class 5 cleanliness level, 100% laminar airflow is essential to prevent any deterioration of cleanliness caused by the present of non-laminar airflow. At this cleanliness level, the ceiling must be totally covered by HEPA/ULPA filter and the lighting is usually tear-drop. As the result, all particles come from the personnel , processes and equipment are immediately swept away from the clean area.

Where the ceiling is not fully covered, turbulent zones are present. In this cases, particles introduced or present in the clean area are re-circulated and produce temporary deterioration of the cleanliness level.

HAOAIRTECH high efficiency cleanroom systems with constant temperature and humidity controlled for sterile food and drug production 3


Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. has introduced many advanced machines used in the production of cleanroom systems .
2. HAOAIRTECH ​​will try to be for each product. Get price!
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
