HAOAIRTECH Brand 4v cell filter Rigid box filter manufacture

Company Advantages
1. HAOAIRTECH ridgid air filter is manufactured as per the industry laid guidelines.
2. The product has been approved by creditable quality certificates. The product creates a clean environment to reduce allergy and asthma symptoms
3. To ensure the quality, it will be fully tested by our professional staff. The product prevents viruses and bacteria from spreading
4. The product creates a high cleanliness working environment. HAOAIRTECH has good after-sales service support and sincere service concept for Rigid box filter,hvac filter box.
5. It has low noise and high mobility. HAOAIRTECH has established a 'one-stop' service system from design, development, production to logistics and distribution.

Characteristics:

Dual density media reduces operating cost

Excellent performance in difficult operating conditions

High efficiency low resistance

Rigid metal construction

Deep pleats type water resistance glass fibre media

Turbulent air flow

Supported with aluminum foil clapboard

High temperature and high humidity

Intermittent exposure to water

Efficiency: MERV 14, MERV 13 and MERV 11 .



Operating conditions:

Media	Glass   Fiber
Frame	AL/GL   frame
Clapboard	Aluminum   Foil
Frame thickness (mm)	150/292mm
Screen	Metal   screen
Efficiency	F7/F8
Max Temperature	350 ˚F (177˚C)
Max Humidity	100%





Products Parameter：

Dimension   (mm) (W*H*D)	Rate Air   Flow   (m3/h)	Media   Area    (m2)	Dust   Holding    (g)	Rate   primary Resistance    (Pa)	Finally Resistance      (Pa)	Efficiency
289x594x150	675	4.3	261	<60	250-300	F6
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<80	300-400	F7
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<100	300-400	F8
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185



Application:

Commercial buidings, data centers , food and beverage, hospitality , industry , microelectronics

Healthcare , schools and universities ,pharmaceutical .

Company Features
1. HAOAIRTECH now centers on producing Rigid box filter.
2. Guangzhou HaoAir Purification Technology Co.,Ltd. possess several advanced production lines for producing rigid filter.
3. HAOAIRTECH wishes to be one of the leading hvac air filters supplier in the industry. Check now!
