Company Advantages1. The product prevents viruses and bacteria from spreading. Owing to its various quality attributes, provided best hepa
air filter is highly appreciated by HAOAIRTECH clients.
2. Guangzhou HaoAir Purification Technology Co.,Ltd.'s customer service always works on a professional level. It is certified by SGS corporation and reaches RoHS standard
3. The product creates a clean environment to reduce allergy and asthma symptoms. Compared with normal hepa
filter manufacturers,hvac hepa filter, hepa filter for cleanroom possess the combination of excellent performance and long service life.
4. The product is widely used for high-end clean rooms of various manufacturers. hepa air filter,hepa room filter has excellent performance, stable and reliable quality.
5. Thanks to the
custom hepa filter system, there is no need to air filter home. The product dedicates to keeping a cleanliness class of 10000-300000.
Characteristics
The carve box folds can prevent the breakage of the filter material.
Neoprene /EVA gasket prevent the air leaking in operation.
Extrude and anodized aluminum frame in 120mm, 150mm, 220mm for choose.
Adopting the laser to scan the filter one by one (MPPS).
100 % provide the test report for each mini-pleats HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.99%-99.999%@0.3um
/ Operating Conditions
Media | Super glass fibre |
Frame | AL/GL/MDF frame |
Gasket | Neoprene /EVA or PU |
Media spacer | Hot melt |
Frame thickness (mm) | 120/150/220 |
Clapboard | 0.035mm aluminum foil |
Efficiency | 99.99%-99.999%@0.3um |
Max Temperature | 80℃ |
Max Humidity | 80% |
/ Products Parameter
Dimension(mm)
(W*H*D) | Rate Air Flow (m3/h) | Media Area (m2) | Dust Holding (g) | Rate primary Resistance(Pa)(H13-H14) | Finally Resistance (Pa) |
484X484X120 | 450 | 4.4 | 230 | 220Pa | 400-600pa |
610X610X120 | 700 | 7.1 | 370 |
610X915X120 | 1050 | 10.6 | 560 |
610X1220X120 | 1400 | 14.1 | 740 |
484X484X150 | 600 | 6 | 320 |
610X610X150 | 1000 | 9.7 | 510 |
610X915X150 | 1500 | 14.5 | 770 |
610X1220X150 | 2000 | 19.3 | 1020 |
484X484X220 | 1000 | 9.8 | 600 |
610X610X220 | 1600 | 15.8 | 920 |
610X915X220 | 2300 | 23.7 | 1340 |
610X1220X220 | 3000 | 31.6 | 1750 |
/ Primary Resistance & Face Velocity Diagram
/ Product Details
part.1
EVA Gasket for Heap air filter with flange
part.2
Outwardly Frame for heap air filter
part.3
Deep Pleats Media Compact
/ package
Company Features1. HAOAIRTECH specializes in manufacturing hepa filter manufacturers with high quality and reasonable price. - Adversity Successfully Overcome Is The Highest Glory. HAOAIRTECH Offers A Wide Range Of hepa air filter, best hepa air filter, hvac hepa filter At Reasonable Price To Customers From All Over The World. Please Contact Us!
2. custom hepa filter is the life of an enterprise which needs the full concentration and meticulous of employees during the work.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. has solidified and advanced its air filter hepa production ability with modern technology. - HAOAIRTECH focuses on continuous technological innovation to improve products and services. Please contact.
