We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.
stainless steel dynamic pass box with laminar air flow for clean room purification workshop
1. With the assistance of the professionals, the production of HAOAIRTECH static pass box is highly efficient and accurate. It acts as an indispensable part in a dustfree production line
2. The product is not easy to get rust even in a humid environment, providing people with many conveniences in cleaning or maintaining it. The product dedicates to keeping a cleanliness class of 10000-300000
3. This product features abrasion resistance. Its fabrics are tough enough to withstand surface wear, rubbing, chafing, and other frictional actions. The product will greatly improve the quality of factory-made products
One row hole on the top door so that the purification air was force out of clean room.
External size: 760*670*690mm
Internal size: 600*600*600mm
External Material: stainless steel304 (t=1.2)
Inside Material: stainless steel304 (t=1.2)
Double layer vacuum glass
Mechanical interlocking
MODEL | HA-PPB500 | HA-PPB600 | HA-PPB700 |
External size (mm) | 660x500x590mm | 760x600x690mm | 860x700x790mm |
Work zone (mm) | 500x500x500mm | 600x600x600mm | 700x700x700mm |
Material （Option） | 1: Entirety Sus304.(T=1.2/1.5mm) | ||
Control system | 1: Both door is mechanical interlocking | ||
UV light | 1 PCS | ||
packing size (mm) | 800x780x850mm | 910x880x940mm | 1100x980x1050mm |
Packing material | Standard Export Poly wood Packing(Fumigant free material) | ||
Introduce
The special design of the negative pressure pass box to form a pressure difference between the positive pressure of the clean room and the negative pressure in contaminated area, it forces the air flow direction from the clean area to the contaminated area always. In this flow process, pass box inside dust on the cargo and the suspended particles in the air are taken away to achieve the possibility of completely avoiding cross contamination. four side inner arc design proved the dust accumulation, Overall seamless connection soft PU Foam gasket have very goods performance in eliminate air leaking problem.
Our Service
1：Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a professional producer for manufacturing dynamic pass box .
2. Guangzhou HaoAir Purification Technology Co.,Ltd.'s core competitiveness lies in its technical strength and rich manufacturing experience.
3. HAOAIRTECH aims to promote exporting pass box clean room . Check now!
