high efficiency transport cart with self contained battery for transporting products HAOAIRTECH
1. The design of HAOAIRTECH transport cart is of professionalism. It is carried out considering many factors such as mechanical structure, spindles, control system, and part tolerances.
2. Internationally-certified quality: The product, tested by the authoritative third-party, has been approved to meet with the widely-recognized international quality standards.
3. Excellent customer service is formed in Guangzhou HaoAir Purification Technology Co.,Ltd..
PLC touchable screen display for operator
DOP /PAO test port for the air filter efficiency
Stainless steel roller conveyor
Vertical laminar air flow
Air speed: 0.45m/s
Dwyer differential gauge
Material: stainless steel304 (t=1.0/1.2)
/ Products Parameter:
MODEL | HA-LSC715A | HA-LSC715B | HA-LSC715C |
External size (mm) (W*D*H) | 715X1000X1900 | 715X1300X1900 | 715X1500X1900 |
Work zone (mm) (W*D*H) | 615X900X650 | 615X1200X650 | 615X1400X650 |
Air speed | 0.45m/s +_20% | ||
Purification rank | ISO5(Class A) | ||
Control system | LCD Control board | ||
Noise | 65dB | ||
Illumination | >300lux | ||
Power | 0.5kw | 0.7kw | 0.9kw |
Illustrate
1: Control Board 2: Pressure differential gauge 3: DOP /PAO Test port 4： Fan 5: Gel seal HEPA filter 6: Glove Hole 7: Unpowered roller 8: Battery
9: UPS 10:Charging Port 11: Universal wheel 12: Feeding Port 14: Per-filter
Introduction:
Haoairtech brand laminar air flow transport carts are designed to transport products in an ISO 4 or ISO 5 environment. that constructed of 304 or 316L stainless steel.
all seams are welded internally utilizing panelized construction. Welds ground smooth and polished. Heavy duty，stainless steel casters, electro-polishing or passivating available.
all carts custom made to client requirements.
1: Easily removable Gel-seal HEPA air filter (rated 99.99% efficiency
@0.3um particles or an ULPA air filter, rated to 99.999% efficient@ 0.12um particles
2: Self-contained battery and charger system designed for continuous use.
typical battery run time 1 to 4 hours.
1：The air flow can be single pass exiting through the bottom of the cart or be recirculating to avoid the leakage of the air.
2: Convenient alternative to vacuum sealing, conveyor transport, and other transfer methods
3: Heavy-duty, cushioned casters ensure smooth rolling over any industrial floor type
4: Isolator gloves allows the operation of hazardous.
1: Pressure gauge alarms and low run time Indicators are standard.
2: 304 Stainless steel construction ensures durability and cleanliness
(electric -polishing available)
/ Certificated
Our Service
1：Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
