high efficiency clean room design vertical laminar flow booth for semiconductor factory

Company Advantages
1. HAOAIRTECH clean room design goes through reasonable designing. Human factors data such as ergonomics, anthropometrics, and proxemics are well applied in the design phase.
2. The product meets rigorous standards for quality and consistency.
3. This product is made to last for years, rather than to be discarded after one or two seasons. It doesn't lose their shape or look worn out after washes.

Product Features：



1:  Standard models are available in US Federal Standard 209E Cleanroom Class 10 to

Class 10,000 cleanliness configurations and various sizes.

2:  Standard soft capsule body is an industrial-grade structure constructed of

Electro-galvanised steel with an abrasion-resistant white oven-baked powder-coated

finish.

3: Standard cleanroom ceiling grid .

4: Standard height is 7' measured from filter face to floor.

5: Free-standing design requires no suspended ceiling supports and allows for a fast and easy installation.

6: Optional castor wheels ensure convenient relocation of the structure after installation.

7: Energy-efficient Airstream Fan Filter Units are easy to install (simply place units on the Soft Capsule's ceiling grid structure) and are available with a wide range of construction configurations.

8: Streamline Soft Capsule cleanrooms use standard 2'x4' Airstream Fan Filter Units.

9: Superior mini-pleat HEPA (99.99% typical efficiency) or ULPA (99.999% typical efficiency) filters provide optimum cleanliness and product protection.

10: Tear-drop style 5000k warm-white fluorescent lighting creates a comfortable working environment.

Products Parameter：





Item		Capsule soft wall cleanroom
Purification   rank		Class10   to class 100.000
Dimension   L*W*H		According client request
Fan   filter unit	Dimension	2x2,2x4,4x4  optional
	Structural   material	Stainless steel, aluminum alloy, AI-Zn   plate
	Power   supply	220V/50HZ AC
Air Filter		Mini-pleats HEPA /ULPA Air filter 99.97%@0.3um  -99.995%@0.3um
Frame   material		Aluminum alloy/stainless steel201/304
Wall   material		Acrylic /sandwich panel/anti-static   acrylic
Ceiling		Aluminium –plastic panel , sandwich panel
Air   conditioner		Constant temperature air conditioning Or Constant temperature and humidity air   conditioning
Fluorescent   Lighting		LED light or T5 (Optional )
Stainless   steel support		D:   8mm x50mm leg
Castor   wheel		Antistatic   PU Material
air   shower		Optional
Pass   box		Optional
Air   flow floor		Optional



 Darw:



Illustration :

1:  Frame   2:   PVC strip curtain    3:Wheel        4：Leg support    5：Fan Filter Unit
