We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

high efficiency clean room classification vertical laminar flow booth online 1
high efficiency clean room classification vertical laminar flow booth online 2
high efficiency clean room classification vertical laminar flow booth online 3
high efficiency clean room classification vertical laminar flow booth online 1
high efficiency clean room classification vertical laminar flow booth online 2
high efficiency clean room classification vertical laminar flow booth online 3

high efficiency clean room classification vertical laminar flow booth online

Brand:
HAOAIRTECH
Model number:
HA-LFB
Material:
Stainless steel 304
OEM /ODM:
OEM/ODM
Certificated:
CE
Start port:
GUANGZHOU
Delivery time:
10 working days after we get the deposite
MOQ:
1sets
Country of Original:
China
Supply ability:
100set/month
Payment term:
100%T/T in advance ,100% LC at sight against with document
Application:
Biology Laboratory Softwall Cleanroom
Inquiry
Product Name
Laboratory Softwall Cleanroom
Other Name
Biology cleanroom
Guarantee Time
12 months
Purificaiton Rank
ISO7/ISO8
Dimension
Customized
Power Supplier
220V/50HZ OR 60HZ
Company Advantages
1. As a competitive product, clean room classification also ranks top in its design.
2. Guangzhou HaoAir Purification Technology Co.,Ltd. has the perfect service quality and rigorous attitude of continuous improvement on clean room classification . It acts as an indispensable part in a dustfree production line
3. The product has been tested for multiple times to be good in its performance and functionality. The product comes with 1-2 years of warranty period
4. The product is reliable in all respects, including quality, performance, durability, etc. The product assures an extremely high-efficient manufacturing process

Biology Laboratory Softwall Cleanroom


high efficiency clean room classification vertical laminar flow booth online 4

        Because no two cleanroom applications are alike, we offer a range of customizable and optional features to give you a laboratory cleanroom that matches your unique requirements.

Lighting: Single and double module lighting options are available. All options include fully sealed housings to maintain ceiling integrity and protect against particulate and contaminant infiltration.

 Frames are designed to allow for bulb/lamp replacement from room side without contaminating clean areas. Fixtures are UL rated and manufactured in accordance with USDA, FDA, and NSF guidelines.


Doors & Entryways: Number and placement of doors can be tailored to your access needs. Single or double entry doors are available, with or without safety viewing windows.

Various heights and widths are available. Other door options include manual sliding doors, automatic rollup doors, and more.


Windows: Window size, quantity, and placement can be customized to your requirements. Standard windows are 3/16” tempered safety glass; double pane, wire, UV tinted,

and polycarbonate windows are also available.


Electrical Options: Factory-installed raceways with pre-wired connections for light switches and 110v outlets can be included in any quantity and location you need.

All raceways include UL-listed components conforming to National Electric Codes. Other power options are also available.


Ceiling Grids & Tiles: Numerous standard and specialty grid sizes, finishes, and gaskets are available, as needed. Standard laboratory cleanroom ceiling tiles are 1/2” sheetrock

core with vinyl facing on one side and sealed edges. Other core and facing materials are available.


Wall Materials: We offer an array of wall panel options. Cores can be manufactured from expanded polystyrene, isocyanurate, or gypsum. Available finishes include vinyl,

high pressure laminates, FRP (fiberglass reinforced plastic), painted steel, and conductive or non-conductive painted aluminum.


Air Showers & Pass-Thru Chambers: To maintain the cleanliness of your laboratory cleanroom when personnel, samples, or equipment must go in and out,

we offer fully-sealed air showers with 99.97% absolute filters and pass-thru chambers in a variety of sizes and configurations.



Parameter

ModelHA-1500HA-2000HA-3000HA-5000
External Size (W*D*H)1500*2000*2530mm2000*3000*2530mm3000*4000*2530mm5000*5000*2530mm
HEPA Filters99.999% efficiency at 0.3 um
Consumption500W800W1000W1600W
FFU Nos.4 pcs6 pcs12 pcs25 pcs
Clean LevelISO 5 (Class 100), Class A
Control Systemcontrol box
Rectangular Tube MaterialSUS 304 material frame
Wall MaterialAnti-static dustproof curtain
BlowerBuilt-in centrifugal blower; speed adjustable
UV LampEmission of 253.7nanometers, with UV timer
Air Velocity0.1~0.6m/s, average 0.45m/s
Noise≤58db
Power SupplyAC220V±10%, 50/60Hz; 110V±10%, 60Hz
Gross Weight390Kg670Kg1100Kg2900Kg
Package Size (W*D*H)

2110*930*920mm

2260*660*500mm

3080*980*1260mm

3080*660*550mm

3080*980*1260mm

3080*980*1260mm

4080*660*550mm



4080*980*1260mm

4080*980*1260mm

4080*980*1260mm

1260*660*1260mm

5080*460*500mm

Customized design for clean level, size or material is available

high efficiency clean room classification vertical laminar flow booth online 5



Company Features
1. The position of HAOAIRTECH in clean room classification has improved greatly.
2. Guangzhou HaoAir Purification Technology Co.,Ltd. owns a professional team of technicians to keep improving our portable clean room .
3. We have the confidence to handle environmental pollution issues. We are planning to bring in new waste treatment facilities to handle and dispose of wastewater and waste gases in line with international best practice.
Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
