We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.
HAOAIRTECH vertical clean room carts supplier online
1. The features of clean room carts are simple, easy to handle and very convenient-used to customers. A sample of the product can be offered for the confirmation of quality
2. With many good characteristics, the product has achieved wide market application. With premium quality, the product is also fit for working under difficult operating conditions
3. This product has a perfect cushioning effect. It will not tend to crack or break under repeated impacts from the foot and ground. It has low noise and high mobility
4. The product is safe. Made of skin-friendly materials that contain no or limited chemicals, it does no harm to health. The product has passed strict air speed test
5. This product stands out for its flexibility. It has the ability to bear a lot of flexural forces and pressure during its working life without losing its strength and elasticity property. The product focuses on the good physical conditions of the workers in the workshop
PLC touchable screen display for operator
DOP /PAO test port for the air filter efficiency
Stainless steel roller conveyor
Vertical laminar air flow
Air speed: 0.45m/s
Dwyer differential gauge
Material: stainless steel304 (t=1.0/1.2)
/ Products Parameter:
MODEL | HA-LSC715A | HA-LSC715B | HA-LSC715C |
External size (mm) (W*D*H) | 715X1000X1900 | 715X1300X1900 | 715X1500X1900 |
Work zone (mm) (W*D*H) | 615X900X650 | 615X1200X650 | 615X1400X650 |
Air speed | 0.45m/s +_20% | ||
Purification rank | ISO5(Class A) | ||
Control system | LCD Control board | ||
Noise | 65dB | ||
Illumination | >300lux | ||
Power | 0.5kw | 0.7kw | 0.9kw |
Illustrate
1: Control Board 2: Pressure differential gauge 3: DOP /PAO Test port 4： Fan 5: Gel seal HEPA filter 6: Glove Hole 7: Unpowered roller 8: Battery
9: UPS 10:Charging Port 11: Universal wheel 12: Feeding Port 14: Per-filter
Introduction:
Haoairtech brand laminar air flow transport carts are designed to transport products in an ISO 4 or ISO 5 environment. that constructed of 304 or 316L stainless steel.
all seams are welded internally utilizing panelized construction. Welds ground smooth and polished. Heavy duty，stainless steel casters, electro-polishing or passivating available.
all carts custom made to client requirements.
1: Easily removable Gel-seal HEPA air filter (rated 99.99% efficiency
@0.3um particles or an ULPA air filter, rated to 99.999% efficient@ 0.12um particles
2: Self-contained battery and charger system designed for continuous use.
typical battery run time 1 to 4 hours.
1：The air flow can be single pass exiting through the bottom of the cart or be recirculating to avoid the leakage of the air.
2: Convenient alternative to vacuum sealing, conveyor transport, and other transfer methods
3: Heavy-duty, cushioned casters ensure smooth rolling over any industrial floor type
4: Isolator gloves allows the operation of hazardous.
1: Pressure gauge alarms and low run time Indicators are standard.
2: 304 Stainless steel construction ensures durability and cleanliness
(electric -polishing available)
/ Certificated
Our Service
1：Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is professional and experienced in developing and manufacturing lab cart. We are known in the market for providing high-quality products. Our production capacity occupies steadily in the forefront of the clean room carts industry.
2. Our professional equipment allows us to fabricate such transport cart .
3. Strict tests have been conducted for laminar flow transport cart . Guangzhou HaoAir Purification Technology Co.,Ltd. strives to deliver value to our users and be a socially responsible corporation. Check it!
