We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

HAOAIRTECH ulpa filter with dop port for air cleaner 1

HAOAIRTECH ulpa filter with dop port for air cleaner 2

HAOAIRTECH ulpa filter with dop port for air cleaner 3

HAOAIRTECH ulpa filter with dop port for air cleaner 4

HAOAIRTECH ulpa filter with dop port for air cleaner 5

HAOAIRTECH ulpa filter with dop port for air cleaner 6

HAOAIRTECH ulpa filter with dop port for air cleaner 7

HAOAIRTECH ulpa filter with dop port for air cleaner 8

HAOAIRTECH ulpa filter with dop port for air cleaner 9

HAOAIRTECH ulpa filter with dop port for air cleaner

Brand:

HAOAIRTECH

Model number:

HA-HEPA-R Series

OEM /ODM:

Yes

Certificated:

Rosh

Start port:

Guangzhou

Delivery time:

8 working days after we get the deposit.

MOQ:

10sets

Country of Original:

China

Supply ability:

500set/one month

Payment term:

T/T , L/C , Western union

Application:

Clean room

Inquiry

Enterprise Strength

HaoAir takes constant innovation and improvement on the service model and strives to provide efficient and considerate services for customers.

Product Details

HaoAir's air showers is processed based on advanced technology. It has excellent performances in the following details.HaoAir provides diversified choices for customers. air showers is available in a wide range of types and styles, in good quality and in reasonable price.

Company Advantages
1. Reliable raw materials: the raw materials of HAOAIRTECH air filter machine are all sourced from the suppliers who have established long term reliable cooperation with us. Their products are all certified.
2. The product features a long service life. The polyester fabric used features high UV resistance and PVC coatings to withstand all the possible weather elements.
3. The product is soft, easy to care, and generally quite affordable. If one wants high-quality bedding, this is an option.

Characteristics

The Replaceable HEPA filter with hood cabinet are designed in closed integration which prevent the air leakage. Meanwhile the heap filter replaceable from cleanroom inside.
This filter light weight and easy maintain
Air duct is galvanized steel and the diameter is 250mm, 300mm and 350mm for your choose
Control valve for air flow adjust (optional).
The media material is super glass fibre for 0.3um particulate.
100 % provide the test report for each mini-pleats HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um

HAOAIRTECH ulpa filter with dop port for air cleaner 11

/ Operating Conditions

Media	Super glass fibre
Frame	AL/GL frame
Gasket	Neoprene /EVA
Media spacer	Hot melt
cabinet thickness (mm)	150/180mm
Filter frame	69mm
Efficiency	99.99%-99.999%@0.3um
Max Temperature	70℃
Max Humidity	100%

/ Products Parameter

Cabinet size(mm) (WHD)	Filter size(mm) (WHD)	Rate Air Flow (m3/h)	Media Area (m2)	Dust Holding (g)	Rate primary Resistance (Pa)	Finally Resistance (Pa)	Efficiency
360X360X180	320x320x69	264	2.93	126	<220pa	400-600pa	H13-H14
524X524X180	484x484x69	600	6.61	397
650X650X180	610x610x69	1000	10.44	627
670X670X180	630x630x69	1050	11.13	668
650X955X180	610x915x69	1500	15.42	925
650x1260x180	610x1220x69	2000	20.40	1224
670x1300x180	630x1260x69	2100	21.76	1306
345x345x180	305x305x69	240	2.66	160
345x650x180	305x610x69	500	5.09	305
345x955x180	305x915x69	750	7.52	450
640x640x180	600x600x69	980	10.11	607
640x1240x180	600x1200x69	1980	19.74	1185
650x1280x180	610x1240x69	2050	20.74	1244
524x1008x180	484x968x69	1250	12.85	771

/ Product Details

part.1

Replaceable HEPA air filter

HAOAIRTECH ulpa filter with dop port for air cleaner 12

part.2

Replaceable HEPA air filter

HAOAIRTECH ulpa filter with dop port for air cleaner 13

part.3

Mini-Pleats Media Compact

HAOAIRTECH ulpa filter with dop port for air cleaner 14

part.4

Air Filter Dust Detection Test

HAOAIRTECH ulpa filter with dop port for air cleaner 15

Application

The replaceable HEPA air filter with hood suitable for high and strict working environment such as surgery, lab, pharmacy , micro-electric ,film production in terminal filtration of the air-condition filtration system

/ package

HAOAIRTECH ulpa filter with dop port for air cleaner 16

HAOAIRTECH ulpa filter with dop port for air cleaner 17

HAOAIRTECH ulpa filter with dop port for air cleaner 18

Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a professional and large-scale Chinese ulpa filter manufacturer.
2. Our company is supported by a dedicated management team. The team is highly responsible for putting together the business strategy and ensuring the business objectives are met.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. will be in endless pursuit of better hepa filter h14 . Get more info! Maximized mutual benefits is Guangzhou HaoAir Purification Technology Co.,Ltd.'s biggest principle. Get more info!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.

Disposable mini-pleats HEPA Air Filter With Hood

Electronical Laboratory Pass Box To Clean Room

High Efficient Auto Door Air Shower

Air Shower Pass Box Clean Room

Industry Automatic Sole cleaning machine for cleanroom air shower

HaoAirTech has become one of the most competitive air filter manufacturers with key strengths in industry experience, professional team and premium services.
