We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

HAOAIRTECH Rigid box filter with big air volume for commercial buidings 1
HAOAIRTECH Rigid box filter with big air volume for commercial buidings 1

HAOAIRTECH Rigid box filter with big air volume for commercial buidings

Brand:
Haoairtech
Model number:
HA-VCF
Material:
glass fibre media
OEM /ODM:
OEM
Certificated:
SGS , Rosh
Start port:
Huangpu
Delivery time:
7 working days
MOQ:
10 pcs
Country of Original:
china
Supply ability:
2000set / month
Payment term:
T/T , LC
Application:
cleanroom terminal filtration
Inquiry
Company Advantages
1. HAOAIRTECH hvac air filter box is professionally manufactured with the help of CNC machines. This process is carried out by our highly qualified workers using turning, milling, and boring machines. With the shell galvanized, the product is crack-resistant and wear-resistant
2. Guangzhou HaoAir Purification Technology Co.,Ltd. has formed a core competitive advantage of 'rapid product innovation, specialization in production, and timely delivery'. The product can increase the rate of finished products
3. It is characterized by exceptional bacteria resistance. It has an antimicrobial surface that is designed to reduce the spread of critters and bacteria. Made of stainless steel SUS304, it is beautiful and durable
4. This product is anti-static. It does not allow the build-up of static electricity to occur when fabrics experience friction or rubbing.

Products Characteristics:

Big air volume

Low Resistance

High dust holding capacity

ABS frame comply with Rosh test report

Both side with screen protect the media

PU gasket or EVA gasket for your choose .

 Introduction:

The media material is super glass fibre for 0.5um particulate

 It is patent technology to ensure the V type passage in low resistance.

 Neoprene /EVA prevent the air leaking in operation

ABS/PVC frame in 3V,4V,5V for your choose.

 Adopting the laser to scan the filter one by one ( MPPS)

 100 % provide the test report for each V Cell air filter

 Filtration Efficiency: F9.F8,F7,F6,(ASHAR ).

Applied to the terminal filtration of the air-condition filtration system


Products Parameter

 Dimension

  (mm)

(W*H*D)

Pack

NO

 Rate

Air Flow

 (m3/h)

Media Area

(m2)

Dust

Holding

   (g)

Efficiency

Rate primary

Resistance

   (Pa)

 Finally

Resistance

   (Pa)

592X287X292

4

2100

11.02

660

F7

65%@0.5um



<80Pa



300-350pa

592X490X292

4

3550

18.6

1200

592X592X292

4

4500

22.1

1350

610X610X292

5

5400

29

1750

592X287X292

4

2100

11.02

660

F8

85%@0.5um



<100pa



350-400pa

592X490X292

4

3550

18.6

1200

592X592X292

4

4500

22.1

1350

610X610X292

4

5400

29

1750

592X287X292

4

2100

11.02

660

F9

90%@0.5um



<120pa



400-450pa

592X490X292

4

3550

18.6

1200

592X592X292

4

4500

22.1

1350

610X610X292

5

5400

29

1750


Application:



1: Optical electronics, biological pharmaceuticals, medical laboratories, food and beverages, daily chemical semiconductors, precision instruments and other

   industries Pre filtration of central ventilation and air conditioning systems in ordinary industrial plants or cleanrooms

2: Ventilation and air conditioning systems for large civil buildings, such as office buildings,

3: Conference rooms, hospitals, shopping malls, gymnasiums, airports, etc.





Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. has excellent R&D capabilities.
2. We run sustainability practices through our sustainable operations. For example, we constantly upgrade our production technologies to reduce water waste and CO2 emissions.
