We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.
HAOAIRTECH laminar flow chamber with hepa filtred for biology horizontal
-
v s
1. HAOAIRTECH laminar flow chamber is fabricated with excellent production and perfect testing methods.
2. laminar flow chamber is mainly consisted of the vertical laminar flow hood . It realizes laminar air flow chamber .
3. This product has very good characteristics and is widely used in the market.
LCD control board with air speed control in three level at least
Negative Pressure Laminar Flow
GMP Modular design with minimized joints and seams.
2 different filters configuration available utilizing combination G1, H14 and PLF Screens .
Gel sealant HEPA Air Filter(99.995%@0.3um) for high purification rank
DOP/PAO Test port for your make the air filter efficiency test
Purification rank: Class100 /ISO5
Air speed: 0.45m/s+_20%10% Exhaust air leaking (Adjustable)
Introduction
Laminar air flow hood provide operator, process and product protection by utilizing HEPA filtered unidirectional laminar air flow booth to maintain an ISO5 environment at rest within the work zone and capture particulates during open handling processes .
MODEL | HA-DB1000 | HA-DB1500 | HA-DB2000 |
External size (mm) | 1200x1500x2400mm | 1500x1700x2400mm | 2000x1800x2400mm |
Work zone (mm) | 1100x1200x2000mm | 1400x1200x2000mm | 1900x1300x2000mm |
Purification rank | Class 100(ISO5) | ||
Air speed | 0.45m/s +_20% | ||
Material（Option） | 1: Entirety Stainless Steel 201/304/316.(T=1.2/1.5mm) | ||
Control system | 1: LCD touchable screen display with air speed adjustable and constant temperature and constant humidity data check. | ||
Noise level(dB) | <65dB | ||
Filter step | 3 Step | ||
HEPA filter | 99.995% @ 0.3um Gel sealant mini--pleats HEPA Air Filter | ||
Secondary filter | F8 pocket air filter | ||
Pre-filter Efficiency | G4 Z-Line panel air filter | ||
Power supply | 380V/50HZ OR 220V/50HZ | ||
Packing material | Standard Export Poly wood Packing(Fumigant free material) | ||
Application
Weighting booth is designed such that through the different configurations it can be applied but not limited to the follow field : food ,electronic, robotic, nutraceutical, animal , cosmetic , biological , and pharmaceutical .
/ Certificated
Our Service
1：Document
A: Document for custom clear: 1 sets
B: Assemble draw: 1 pcs
C: Circuit diagram draw: 1 pcs
D: Test report : 1sets
E: Additional IQ/OQ/PQ document is available upon request.
2: Air Shower Spare Part so that you can replacement in future by yourself:
A: HEPA air filter +Pre-filter (as your request)
Note: HEPA air filter should be replacement in half and one year. Pre-filter
should be replacement in each 6 months, but it can refresh no more than 3 times
B: Sensor (As your request)
C: Control board (as your request)
3: The air shower guarantee time is 2 years excluding consumable parts and accessories .
Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a Chinese company that specializes in the design, production, and sale of laminar flow chamber .
2. Our products are sold on an international scale, which brings consistent and attractive revenue growth. We are able to meet our underlying revenue growth target each year.
3. Our company bears social responsibilities. We recycle as many materials as possible, and to do so in a way that is congruent with other aspects of sustainability. Our company is committed to sustainability in the value chain. This commitment applies to quality assurance, occupational safety, environmental protection and sustainable manufacturing processes and performance in our products. Our company bears social responsibilities. To make our manufacturing unit sustainable in the long term, we make efforts to carry out solar and wind energy projects.
Email: sales2@haoairtech.com
Add: RM323 KaiSheng Building,CongYun RoadYongping street ,Baiyun District, Guang Zhou, Guangdong, China
