Company Advantages1. Regarding the quality management of HAOAIRTECH best hepa
air filter , it is demanded to pass through the extremely harsh quality control and inspection required for gift and crafts.
2. The positive market response indicates the good market prospect of the product. The product prevents viruses and bacteria from spreading
3. The offered products are in complete compliance with quality industry standards. The product has passed strict air speed test
4. This product defines the meaning of remarkable quality and long-lasting stability. The product creates a clean environment to reduce allergy and asthma symptoms
Characteristics
The media material is super glass fibre for 0.3um particulate
It is patent technology to ensure the V type passage in low resistance.
Neoprene /EVA prevent the air leaking in operation
GL or AL material frame for your choose.
V Type special frame can let the hepa air filter have more big media area.
More high air volume and more lower resistance
Adopting the laser to scan the filter one by one ( MPPS)
100 % provide the test report for each V-Bank HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um
Applied to the terminal filtration of the air-condition filtration system
/ Products Parameter
Dimension(mm)
(W*H*D) | Pack NO | Rate Air Flow
(m3/h) | Media Area
(m2) | Dust Holding
(g) | Rate primary Resistance(Pa)
(H13-H14) | Finally
Resistance
(Pa) |
285X285X292 | 2 | 700 | 5.42 | 325 | 220pa | 400-600pa |
592X592X292 | 3 | 2100 | 16.43 | 986 |
592X592X292 | 4 | 2800 | 21.91 | 1315 |
610X610X292 | 5 | 3600 | 28 | 1692 |
610X915X292 | 6 | 4300 | 34 | 2031 |
484X484X292 | 3 | 1700 | 13.5 | 811 |
610X305X292 | 5 | 1800 | 14.5 | 866 |
305X610X292 | 3 | 2150 | 17 | 1015 |
630X630X292 | 5 | 3700 | 29 | 1746 |
600X600X292 | 5 | 3500 | 27 | 1665 |
570X570X292 | 4 | 2700 | 21 | 1267 |
320X320X292 | 3 | 1150 | 9 | 544 |
515X515X292 | 4 | 2400 | 19 | 1148 |
610X484X292 | 5 | 2850 | 22.5 | 1351 |
490X592X292 | 4 | 2800 | 22 | 1315 |
592X490X292 | 4 | 2300 | 18 | 1094 |
/ Primary Resistance & Face Velocity Diagram
![HAOAIRTECH disposable hepa filter h12 with dop port for dust colletor hospital 12]()
/ Product Details
part.1
Hepa Air Filter With EVA Gasket
part.2
Hepa Air Filter With EVA Gasket
part.3
Mini-Pleats Media Compact
part.4
Air Filter Dust Detection Test
Application
V Bank HEPA air filter suitable for hospital, electronic industry ,food,Pharmaceutical ,
bioengineering,precision instrument, electron semiconductors and dust-free room, national defense,aerospace field and so on .
/ package
Company Features1. hepa filter h12 produced by Guangzhou HaoAir Purification Technology Co.,Ltd. is in a leading position in China.
2. We recently imported a series of advanced production facilities. This empowers us to manufacture products at the highest level and speed and meet exacting specifications.
3. Our company runs in line with "customer first, integrity first" business philosophy. We aim to hold a stable status in the market taking this philosophy as our basis.
