HAOAIRTECH ashare v cell rigid filter with abs frame for food and beverage

Company Advantages
1. HAOAIRTECH v cell rigid filter has to go through the following inspection processes. It is checked for its appearance (surface defects, color inconsistency, etc. ), specifications conformance, and form, fit, & function. The product creates a clean environment to reduce allergy and asthma symptoms
2. People said that this product allows less frequent replacement. Therefore they are able to save maintenance costs as many as possible. The product prevents airborne particles and microbes from entrance
3. This product has the advantages of long service life and excellent performance. The product has passed strict air speed test
4. The product is tested to meet the quality standards as per the customer demands. The product comes with 1-2 years of warranty period

Characteristics:

Dual density media reduces operating cost

Excellent performance in difficult operating conditions

High efficiency low resistance

Rigid metal construction

Deep pleats type water resistance glass fibre media

Turbulent air flow

Supported with aluminum foil clapboard

High temperature and high humidity

Intermittent exposure to water

Efficiency: MERV 14, MERV 13 and MERV 11 .



Operating conditions:

Media	Glass  fiber with foil clapboard
Frame	Aluminium/ galvainzed frame
Clapboard	Aluminum   Foil
Frame thickness (mm)	120、150/292mm
Screen	Metal   screen
Efficiency	F6/F7/F8/ F9
Max Temperature	350 ˚F (177˚C)
Max Humidity	100%





Products Parameter：

Dimension   (mm) (W*H*D)	Rate Air   Flow   (m3/h)	Media   Area    (m2)	Dust   Holding    (g)	Rate   primary Resistance    (Pa)	Finally Resistance      (Pa)	Efficiency
289x594x150	675	4.3	261	<60	250-300	F6
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<80	300-400	F7
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185
289x594x150	675	4.3	261	<100	300-400	F8
594x594x150	1385	8.84	354
287x594x292	1490	9.52	571
594x594x292	3085	19.7	1185



Application:

Commercial buidings, data centers , food and beverage, hospitality , industry , microelectronics

Healthcare , schools and universities ,pharmaceutical

  Picture :

1: Galvanized material frame in interlocker style :                    2: Both side is flange without any screw。

3: Both side is metal screen with one bard for endure high air volume.





Company Features
1. As a domestically and internationally competitive enterprise, Guangzhou HaoAir Purification Technology Co.,Ltd. primarily focuses on v cell rigid filter . Guangzhou HaoAir Purification Technology Co.,Ltd. possesses first-class production capacity in hvac air filters industry.
2. Guangzhou HaoAir Purification Technology Co.,Ltd. has an independent product development center.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. has established many Rigid box filter production bases and marketing networks in the world. Aiming to be the top brand in hvac filter box field, Guangzhou HaoAir Purification Technology Co.,Ltd. take the tenet of hvac air filter box . Contact us!
