We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.

Gel Seal HEPA Air filter with 99.995%@0.3um 1
Gel Seal HEPA Air filter with 99.995%@0.3um 2
Gel Seal HEPA Air filter with 99.995%@0.3um 3
Gel Seal HEPA Air filter with 99.995%@0.3um 4
Gel Seal HEPA Air filter with 99.995%@0.3um 1
Gel Seal HEPA Air filter with 99.995%@0.3um 2
Gel Seal HEPA Air filter with 99.995%@0.3um 3
Gel Seal HEPA Air filter with 99.995%@0.3um 4

Gel Seal HEPA Air filter with 99.995%@0.3um

    oops...!

    no product data.

    Go to homepage



    Characteristics
    The Gel Seal HEPA filter use the super glass fibre filtration 0.3um particulate.
    Patent technology to ensure the V type passage in low resistance.
    Gel Seal gasket can 100% prevent the air leaking in operation.
    Extrude and anodized aluminum frame in  69mm, 93mm, 96mm.104mm for choose.
    While color metal screen to protect the filtration media without any damage .
    Light weight and easy to install
    Adopting the laser to scan the filter one by one ( MPPS).
    100 % provide the test report for each mini-pleats HEPA air filter
    Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um
    Applied to the terminal filtration of the air-condition filtration system
    Gel Seal HEPA Air filter with 99.995%@0.3um 5



    / Operating Conditions


     Media

    Super    glass fibre

     Frame

    AL frame    in 69/96/96/104mm

    Gasket

    Gel Seal

    Media spacer

    Hot melt

    Screen

    Metal    screen

    Efficiency

    >99.999%@0.3um

    Max Temperature

     70℃

    Max Humidity

    100%



    / Products Parameter


    Cabinet siz(mm)
    (W*H*D)

    Rate
    Air Flow
     (m3/h)

    Media Area
     (m2)

    Dus Holding
    (g)

    Rate primary
     Resistance
    (Pa)

    Finally
     Resistance
    (Pa)

    Efficiency

    510X510X69

    600

    6.6

    400














    <200pa














    400-600pa














    H13-H14



    636X636X69

    1000

    10.7

    650

    596X1196X69

    1800

    18.3

    1100

    636X1236X69

    2100

    21.3

    1000

    346X346X93

    400

    4.2

    250

    510X510X93

    900

    9.42

    565

    636X636X93

    1500

    14.9

    900

    636X941X93

    2000

    22.3

    1200

    626X1226X93

    2800

    29.8

    1800

    621X621X93

    1380

    14.19

    851

    636X1246X93

    2800

    29.8

    1800

    596X1196X93

    2550

    26.28

    1577

    656X994X93

    2350

    24.15

    1449

    350X350X96

    500

    4.68

    300

    514X514X96

    1000

    10.62

    650

    640X640X96

    1500

    16.8

    1000



    / Product Details



    part.1
    Gel seal HEPA air filter
    Gel Seal HEPA Air filter with 99.995%@0.3um 6

    part.2
    Mini-Pleats Media Compact
    Gel Seal HEPA Air filter with 99.995%@0.3um 7

    part.3
    Air Filter Dust Detection Test
    Gel Seal HEPA Air filter with 99.995%@0.3um 8



    / package


    Gel Seal HEPA Air filter with 99.995%@0.3um 9
    Gel Seal HEPA Air filter with 99.995%@0.3um 10
    Gel Seal HEPA Air filter with 99.995%@0.3um 11
