cell gl 4v HAOAIRTECH Brand Rigid box filter

Company Advantages
1. The material of ridgid air filter is well-selected by HaoAir Purification . It acts as an indispensable part in a dustfree production line
2. Automatic operation is the highlight of the product. Compared with other products, Rigid box filter,hvac filter box has advantages such as hvac air filter box and residential air filters.
3. Anytime there is problem for our rigid filter, we will provide timely help. The product comes with 1-2 years of warranty period
4. HAOAIRTECH is well established selling hvac air filters to all types of retailers including the Chinese and foreigners. The product dedicates to keeping a cleanliness class of 10000-300000

Products Characteristics:

Big air volume

Low Resistance

High dust holding capacity

ABS frame comply with Rosh test report

Both side with screen protect the media

PU gasket or EVA gasket for your choose .

 Introduction:

The media material is super glass fibre for 0.5um particulate

 It is patent technology to ensure the V type passage in low resistance.

 Neoprene /EVA prevent the air leaking in operation

ABS/PVC frame in 3V,4V,5V for your choose.

 Adopting the laser to scan the filter one by one ( MPPS)

 100 % provide the test report for each V Cell air filter

 Filtration Efficiency: F9.F8,F7,F6,(ASHAR ).

Applied to the terminal filtration of the air-condition filtration system

Products Parameter：

Dimension   (mm) (W*H*D)	Pack NO	Rate Air Flow  (m3/h)	Media Area (m2)	Dust Holding    (g)	Efficiency	Rate primary Resistance    (Pa)	Finally Resistance    (Pa)
592X287X292	4	2100	11.02	660	F7 65%@0.5um	<80Pa	300-350pa
592X490X292	4	3550	18.6	1200
592X592X292	4	4500	22.1	1350
610X610X292	5	5400	29	1750
592X287X292	4	2100	11.02	660	F8 85%@0.5um	<100pa	350-400pa
592X490X292	4	3550	18.6	1200
592X592X292	4	4500	22.1	1350
610X610X292	4	5400	29	1750
592X287X292	4	2100	11.02	660	F9 90%@0.5um	<120pa	400-450pa
592X490X292	4	3550	18.6	1200
592X592X292	4	4500	22.1	1350
610X610X292	5	5400	29	1750

Application:



1: Optical electronics, biological pharmaceuticals, medical laboratories, food and beverages, daily chemical semiconductors, precision instruments and other

   industries Pre filtration of central ventilation and air conditioning systems in ordinary industrial plants or cleanrooms

2: Ventilation and air conditioning systems for large civil buildings, such as office buildings,

3: Conference rooms, hospitals, shopping malls, gymnasiums, airports, etc.



Company Features
1. Guangzhou HaoAir Purification Technology Co.,Ltd. is a company which is specialized in producing Rigid box filter covering a wide range of working area.
2. In addition, Guangzhou HaoAir Purification Technology Co.,Ltd. also has a first-class product R&D team with years of rigid filter product R&D experience.
3. HaoAir Purification can provide far more value for you than other brands. Contact!
