Company Advantages1. The product is of high purification rank. We are specialized in manufacturing best hepa
air filter in superb quality. The product is of high purification rank
2. High quality materials are adopted to ensure the safety of hepa
filter manufacturers during the delivery. Automatic operation is the highlight of the product
3. The product comes with 1-2 years of warranty period, HAOAIRTECH Is Dedicated To Offer Professional Service And Competitive Prices For The product comes with 1-2 years of warranty period, HAOAIRTECH's hepa air filter.
4. The product creates a high cleanliness working environment, HAOAIRTECH Is Sure To Offer You Best Quality
custom hepa filter And Excellent After-Sale Service.
Characteristics
The media material is super glass fibre for 0.3um particulate
It is patent technology to ensure the V type passage in low resistance.
Neoprene /EVA prevent the air leaking in operation
GL or AL material frame for your choose.
V Type special frame can let the hepa air filter have more big media area.
More high air volume and more lower resistance
Adopting the laser to scan the filter one by one ( MPPS)
100 % provide the test report for each V-Bank HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um
Applied to the terminal filtration of the air-condition filtration system
/ Products Parameter
Dimension(mm)
(W*H*D) | Pack NO | Rate Air Flow
(m3/h) | Media Area
(m2) | Dust Holding
(g) | Rate primary Resistance(Pa)
(H13-H14) | Finally
Resistance
(Pa) |
285X285X292 | 2 | 700 | 5.42 | 325 | 220pa | 400-600pa |
592X592X292 | 3 | 2100 | 16.43 | 986 |
592X592X292 | 4 | 2800 | 21.91 | 1315 |
610X610X292 | 5 | 3600 | 28 | 1692 |
610X915X292 | 6 | 4300 | 34 | 2031 |
484X484X292 | 3 | 1700 | 13.5 | 811 |
610X305X292 | 5 | 1800 | 14.5 | 866 |
305X610X292 | 3 | 2150 | 17 | 1015 |
630X630X292 | 5 | 3700 | 29 | 1746 |
600X600X292 | 5 | 3500 | 27 | 1665 |
570X570X292 | 4 | 2700 | 21 | 1267 |
320X320X292 | 3 | 1150 | 9 | 544 |
515X515X292 | 4 | 2400 | 19 | 1148 |
610X484X292 | 5 | 2850 | 22.5 | 1351 |
490X592X292 | 4 | 2800 | 22 | 1315 |
592X490X292 | 4 | 2300 | 18 | 1094 |
/ Primary Resistance & Face Velocity Diagram
![best hepa air filter dop hepa filter manufacturers volume company 12]()
/ Product Details
part.1
Hepa Air Filter With EVA Gasket
part.2
Hepa Air Filter With EVA Gasket
part.3
Mini-Pleats Media Compact
part.4
Air Filter Dust Detection Test
Application
V Bank HEPA air filter suitable for hospital, electronic industry ,food,Pharmaceutical ,
bioengineering,precision instrument, electron semiconductors and dust-free room, national defense,aerospace field and so on .
/ package
Company Features1. As a developing company, Guangzhou HaoAir Purification Technology Co.,Ltd. has been developing into manufacturing hepa filter manufacturers. - Steady, measured growth has allowed Guangzhou HaoAir Purification Technology Co.,Ltd. to keep quality control high and product availability consistent.
2. A stable workforce, ongoing technical training and years on the job are the bedrock of our superior performance. HaoAir Purification
3. Our high-quality hepa air filter are made by our experienced technology. - custom hepa filter are provided for the convenience of customers. Ask!
