We have a team that benefits from over 15 years cleanroon equipment fieldwork and experience.
air showers and pass thrus for large scale semiconductor factory HAOAIRTECH
1. HAOAIRTECH air showers and pass thrus has to go through a comprehensive QC check including the performance of filter and membrane, PLC controller, and valves. Made of stainless steel SUS304, it is beautiful and durable
2. Technical support and air showers and pass thrus will be provided by Guangzhou HaoAir Purification Technology Co.,Ltd. for our air shower price . The product is of high purification rank
3. air shower price has the peculiarities of air showers and pass thrus as compared with other similar products. With premium quality, the product is also fit for working under difficult operating conditions
Introduction:
Haoair Air Shower are an effective solution to reduce or even eliminate this type of contamination in order to protect the classification of the controlled enviroment.
Vertical Air Shower is a cabinet type air shower designed to eliminate the particle contamination of the external surfaces of personnel and materials entering into controlled areas.
Top Side Vertical Flow Air Shower General Features:
1.Two doors with tempered safety glass.
2.Door opening direction adjustable to the room requirements.
3.Indication of cycle running.
4.Remaining cycle time.
5.Cycle time adjustable by Administrator from 0-99 seconds (other values can be programmed at the factory).
6.Alarms for blower, ventilation system, clogged filter, entry door open, exit door open, etc.
7.Fully automatic operation with programmable microprocessor to control all functions of the shower.
8.Microprocessor control to differentiate between entering and leaving cycles.
9.LED state indication for doors and shower cycle.
10.Full blown air filtration through 2 mechanical filtration stages with G4 pre-filter and ultra-filtration by HEPA H14 absolute filters.
The air shower is approval by CE and RoHS certificate.
Customer’s design is available.
Top Side Vertical Flow Air Shower Specification:
Top Side Vertical Flow Air Shower HA-AS1400V Series | ||||
Model | HA-AS1400V1 | HA-AS1400V2 | HA-AS1400V3 | |
Outer Si(mm) (WXDXH) | 1400x1000x2180 | 1400x2000x2180 | 1400x3000x2180 | |
Inner Size(mm)(WXDXH) | 800x930x1910 | 800x1930x1910 | 800x2930x1910 | |
Persons per cycle | 1-2 person | 2-4 person | 3-6 person | |
Air shower duration | Factory set at 15 seconds (0-99 seconds adjustable) | |||
Material | Coldrolled Steel with Baked Painting or Stainless steel 304/316 | |||
Fan consumption | 1.1KWX1set | 1.1KWX2sets | 1.1KWX3sets | |
Air flow of fan(m3/h) | 1300m3/h | |||
Fan run (r/min) | 2800r/min | |||
Nozzle in stain less steel | 16 pcs | 32 pcs | 48 pcs | |
Wind speed(m/s) | 25-30m/s | |||
Noise level(dB) | <62dB | |||
LED Fluorescent Lamp | 20wx1 | 20wx2 | 20wx3 | |
HEPA Filter | Size(mm) | 595X595X80mm(mini-pleats HEPA filter) | ||
Efficiency | 99.995%@0.3um | |||
Resistance | <220pa | |||
Pre-filter | Size(mm) | 785x385x21mm | ||
Efficiency | 75% @ 5um | |||
Resistance | <30 Pa | |||
Power supply | 380V/50Hz | |||
Top Side Vertical Flow Air Shower Compared With Traditional Air Shower:
Top Side Vertical Flow Air Shower Application:
