Company Advantages1. The design of HAOAIRTECH v bank filter is meant to meet the needs of users who are in the pursuit of writing, signing, and drawing freely. It is a practical design that can cater to different digital needs. The product stands out for its high efficiency for purification
2. The product has found increasingly wider application in the market due to its remarkable economic benefits. Automatic operation is the highlight of the product
3. The product has a built-in light diffuser that illuminates in a concentrated direction to give the user the right amount of brightness. A sample of the product can be offered for the confirmation of quality
Characteristics
The media material is super glass fibre for 0.3um particulate.
It is patent technology to ensure the V type passage in low resistance.
Neoprene /EVA or PU gasket prevent the air leaking in operation.
Extrude and anodized aluminum frame in 50mm, 69mm, 80mm, 90mm for choose.
While color metal screen to protect the filtration media without any damage.
Light weight and easy to install
Adopting the laser to scan the filter one by one ( MPPS).
100 % provide the test report for each mini-pleats HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.95%-99.995%@0.3um
Applied to the terminal filtration of the air-condition filtration system
/ Operating Conditions
Media | Super glass fibre |
Frame | AL/GL/SUS201/304 frame |
Gasket | Neoprene /EVA or PU |
Media spacer | Hot melt |
Frame thickness (mm) | 46/50/69/80/90/96/120 |
Screen | Metal screen |
Efficiency | >99.999%@0.3um |
Max Temperature | 70℃ |
Max Humidity | 100% |
/ Products Parameter
Dimension(mm)
(W*H*D) | Rate Air Flow
(m3/h) | Media Area
(m2) | Dust Holding (g) | Rate primary Resistance (Pa) | Finally Resistance
(Pa) |
320X320X50 | 200 | 1.99 | 120 | H13 :<200Pa H14 :<220pa | 400-600pa |
484X484X50 | 450 | 4.51 | 270 |
610X610X50 | 700 | 7.13 | 430 |
915X610X50 | 1000 | 10.58 | 650 |
1170X570X50 | 1200 | 12.57 | 750 |
1220X610X50 | 1350 | 14.04 | 850 |
320X320X69 | 250 | 2.89 | 180 |
484X484X69 | 600 | 6.55 | 400 |
610X610X69 | 1000 | 10.37 | 620 |
915X610X69 | 1500 | 15.39 | 920 |
1170X570X69 | 1800 | 18.28 | 1100 |
1220X610X69 | 2000 | 20.41 | 1230 |
484X484X96 | 1000 | 10.24 | 620 |
610X610X96 | 1500 | 16.2 | 980 |
915X610X96 | 2300 | 24.01 | 1450 |
1170X570X96 | 2800 | 28.56 | 1720 |
1220X610X96 | 3100 | 31.89 | 1920 |
/ Primary Resistance & Face Velocity Diagram
![v bank air purifier filter maker online 12]()
/ Product Details
part.1
Hepa Air Filter With EVA Gasket and PU gasket
part.3
Mini-Pleats Media Compact
part.4
Air Filter Dust Detection Test
Application
Mini-pleats HEPA air filter suitable for hospital, electronic industry ,food,Pharmaceutical ,
bioengineering,precision instrument, electron semiconductors and dust-free room, national defense,aerospace field, fan filter unit, HEPA unit , air shower, dynamic pass box, dispensing booth ,softwall cleanroom, laminar flow booth and so on .
/ Our Service
Our Service
1: 100% scann air leaking test for each Mini-PleatsHEPA air flter, test report accompany all of
HEPA air filter.
2: 2 pcs in one carton .each air filter warp by PE Bag .
3: Small order is polywood packing so that we can send out by sea in LCL.
4: If order amount more than 20000USD, We accept the 100% LC at sight against with
document.
5: Free sample possible for you confirmation of quality .
/ package
Company Features1. Guangzhou HaoAir Purification Technology Co.,Ltd. is identified and praised by the market in China. We are a reliable company that has an outstanding capacity in manufacturing v bank filter . Different mechanisms are provided for fabricating different air purifier filter.
2. The quality of our chemical filter still keeps unsurpassed in China.
3. Our professional equipment allows us to fabricate such v cell filter. HAOAIRTECH vigorously pays attention to cultivation of talents which will promote the overall quality of active carbon air filter . Get quote!
