Enterprise Strength
-
HaoAir is dedicated to providing quality services to meet the needs of customers.
Company Advantages1. HAOAIRTECH
custom hepa filter uses insulating materials which not only protect against damage caused by static electricity but also avoid leakage.
2. The QC team has been always paying close attention to the quality of this product.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. is a supplier of focusing on the quality assurance of custom hepa filter .
Characteristics
The carve box folds can prevent the breakage of the filter material.
Neoprene /EVA gasket prevent the air leaking in operation.
Extrude and anodized aluminum frame in 120mm, 150mm, 220mm for choose.
Adopting the laser to scan the filter one by one (MPPS).
100 % provide the test report for each mini-pleats HEPA air filter
Filtration Efficiency: H13 ,H14,(EN1822). 99.99%-99.999%@0.3um
/ Operating Conditions
Media | Super glass fibre |
Frame | AL/GL/MDF frame |
Gasket | Neoprene /EVA or PU |
Media spacer | Hot melt |
Frame thickness (mm) | 120/150/220 |
Clapboard | 0.035mm aluminum foil |
Efficiency | 99.99%-99.999%@0.3um |
Max Temperature | 80℃ |
Max Humidity | 80% |
/ Products Parameter
Dimension(mm)
(W*H*D) | Rate Air Flow (m3/h) | Media Area (m2) | Dust Holding (g) | Rate primary Resistance(Pa)(H13-H14) | Finally Resistance (Pa) |
484X484X120 | 450 | 4.4 | 230 | 220Pa | 400-600pa |
610X610X120 | 700 | 7.1 | 370 |
610X915X120 | 1050 | 10.6 | 560 |
610X1220X120 | 1400 | 14.1 | 740 |
484X484X150 | 600 | 6 | 320 |
610X610X150 | 1000 | 9.7 | 510 |
610X915X150 | 1500 | 14.5 | 770 |
610X1220X150 | 2000 | 19.3 | 1020 |
484X484X220 | 1000 | 9.8 | 600 |
610X610X220 | 1600 | 15.8 | 920 |
610X915X220 | 2300 | 23.7 | 1340 |
610X1220X220 | 3000 | 31.6 | 1750 |
/ Primary Resistance & Face Velocity Diagram
![HAOAIRTECH ulpa custom hepa filter hot sale for electronic industry 11]()
/ Product Details
part.1
EVA Gasket for Heap air filter with flange
part.2
Outwardly Frame for heap air filter
part.3
Deep Pleats Media Compact
/ package
Company Features1. As a grand exporter, Guangzhou HaoAir Purification Technology Co.,Ltd. has been specialized in producing custom hepa filter for years.
2. Guangzhou HaoAir Purification Technology Co.,Ltd. occupies the large h12 hepa filter market share in China.
3. Guangzhou HaoAir Purification Technology Co.,Ltd. is committed to producing the most valuable air purifiers hepa filter with less cost. Inquire now! With cutting-edge technologies, Guangzhou HaoAir Purification Technology Co.,Ltd. aims to premium products and quality services. Inquire now! We should abide by the tenet of ulpa filter . Inquire now!
